Carel Clima - Page 32

32
ENG
clima +030220641 - rel. 1.0 - 07.12.2007
par “CAREL sup
index”
“Modbus
index”
description min max def UOM R/W note
- 37 36 “Status of EEProm alarm
0= not active - 1= active”
01- R
- 38 37 “Serial connection alarm if parameter LIn enabled
0= not active - 1= active”
01- R
- 39 38 “High water temperature alarm for model T+H rad.
0= not active - 1= active”
01- R
- 40 39 “Low water temperature alarm for model T+H rad.
0= not active - 1= active”
01- R
- 49 48 “Reading of dipswitch 4
0= o - 1= on”
01- R
- 50 49 “Reading of dipswitch 1
0= o - 1= on”
01- R
- 51 50 “Reading of dipswitch 2
0= o - 1= on”
01- R
- 52 51 “Reading of dipswitch 3
0= o - 1= on”
01- R
- 53 52 “Digital input reading
1= open - 0= closed “
01- R
Tab. 9.a
Integer variables
par.
CAREL sup.
index
Modbus®
index
description min max def. UOM R/W
note
- 1 150
internal RTC reading in minutes
(e.g.: 13:13 equals 793 min.)
0 1439 - min R/W
- 3 152
status of the mode changeover timer
(day if in night mode, night if in day mode)
0 720 - min R/W
AUt 7 130 parameter AUt 0 7 0 R/W
dI 8 131 parameter dI 0 4 0 R/W
dyS 9 132 parameter dyS 1 4 1 R/W
AdC 10 133 parameter AdC for automatic model selection 1 3 1 R/W
SLP 11 134
duration of the mode changeover timer
(day if in night mode, night if in day mode)
0 12 8 h R/W
- 12 135 day band threshold 0 1439 480 min R/W
- 13 136 night band threshold 0 1439 1200 min R/W
Add 14 137 485 serial address 1 207 1 R
LOC 15 138 parameter LOC 0 2 0 R/W
nEd 16 139 parameter nEd 0 100 0 % R/W
- 17 140 model of unit used 0 7 - R
SFH 18 141 parameter SFH 0 2 0 R/W
PS 19 142 parameter PS (if = 0 no password) 0 999 0 R/W
SEr 20 143 parameter SEr 0 5 1 R/W
Tab. 9.b
Analogue variables
par.
CAREL sup.
index
Modbus®
index
description min max def. UOM R/W
note
- 1 29 built-in NTC temperature sensor -40 70 - C R
the calibration value is
not added
- 2 30 remote NTC temperature sensor -40 80 - C R
the calibration value is
not added
- 3 31 minimum inside temperature recorded from unit ON -40 70 - C R
the calibration value is
not added
- 4 32 maximum inside temperature recorded from unit ON -40 70 - C R
the calibration value is
not added
- 5 33 minimum outside temperature recorded from unit ON -40 80 - C R
the calibration value is
not added
- 6 34 maximum outside temperature recorded from unit ON -40 80 - C R
the calibration value is
not added
- 7 35 digital temperature sensor -40 70 - C R
the calibration value is
not added
- 8 36 digital humidity sensor value 0 99 - %rH R
- 13 41 analogue output value 0 100 - R
- 14 42 PWM value for cooling 0 100 - R/W W if LIn=1
