Carel Clima - Page 33

33
ENG
clima +030220641 - rel. 1.0 - 07.12.2007
par.
CAREL sup.
index
Modbus®
index
description min max def. UOM R/W
note
- 15 43 PWM value for heating 0 100 - R/W W if LIn=1
- 16 44 PWM value for humidi cation 0 100 - R/W W if LIn=1
22 1 day temperature set point in cooling 10 40 24 C R/W
23 2 night temperature set point in cooling 10 40 26 C R/W
24 3 day temperature set point in heating 10 40 20 C R/W
25 4 night temperature set point in heating 10 40 18 C R/W
dIF 26 5 temperature di erential dIF 0 10 1 C R/W
dF2 27 6 temperature di erential dF2 0 10 1 C R/W
dS1 28 7 temperature di erential dS1 -10 10
0.5 T2A+H
0 others
C R/W
dFA 29 8 temperature di erential dFA -10 10 1 C R/W
dSA 30 9 temperature di erential dSA -10 10
0.5 T2A+H
0 others
C R/W
31 10 humidi cation set point 10 70 50 %rH R/W
32 11 dehumidi cation set point 10 70 70 %rH R/W
dFH 33 12 humidi cation di erential dFH 1 20 5 %rH R/W
dFd 34 13 dehumidi cation di erential dFd 1 20 5 %rH R/W
CAL+Int 35 14 inside temperature calibration -10 10 0 C R/W
CAL+ESt 36 15 outside temperature calibration -10 10 0 C R/W
CAL+HUn 37 16 humidity sensor calibration -15 15 0 %rh R/W
CtS 38 17 threshold for set point compensation in cooling 0 25 10 C R/W
Ctt 39 18 threshold for set point compensation in heating 0 25 10 C R/W
CdF 40 19 max di erential for set point compensation 0 20 2 C R/W
CSt 41 20 parameter for set point compensation -1 1 0 R/W
EHi 42 21 maximum water temperature for model T+H radiant 10 80 40 C R/W
ELo 43 22 minimum water temperature for model T+H radiant 0 50 10 C R/W
Tab. 9.c
Note: In the supervisor parameters, the set point for the automatic
modes (day and night) is saved to both values (cooling/heating);
when setting, simply change the heating set point only, and the setting
will be automatically copied to the corresponding cooling set point.
Note: All the analogue variables (set point, di erential, sensor
calibration ...) are expressed in tenths if read with the CAREL
protocol, while they are expressed in hundredths if read with the Modbus®
protocol (example: 24.3 °C: CAREL supervisor = 243, Modbus® supervisor
= 2430)
