24 ir33 platform “connections” +030220445 - rel. 2.3 - 27.04.2011
Tab. 6.a
ENGLISH
mount-in depth
70,5 mm
Mounting smooth and stiff panel using side fastening brackets, pressed until stop
drilling template dimensions 28.8 ± 0.2 x 70.8 ± 0.2 mm
Display digits 3 digit LED
display range from –99 to 999
operating status indicated by graphic icons on the display
Keypad 4 rubber silicon buttons
No options mod H
Infrared receiver mod I,F,K,W
mod E,F,O,W
Clock with backup battery
Alarm or auxiliary relay G,K,O,W
Custom param. or fi rmware IRccxxxxxnx; cc customer; n custom made parameters list
Package IRxxxxxxxxi: blank singol; 1 or 5 multiple; K kit with probes
Buzzer available on all the models
Clock error at 25 °C ±10 ppm (±5.3 min/year)
error in the temperature range -10T60 °C -50 ppm (-27 min/year)
ageing < ±5 ppm (±2.7 min/year)
discharge time typical 6 months (max. 8 months)
recharge time typical 5 hours (< max. 8 hours)
Operating temperature -10T60 °C for the versions IRxxxx(0,L)(H,I,E,F,G,K,O,W)xx
-10T50 °C for the versions IRxxxx(H)(H,I,E,F,G,K,O,W)xx
Operating humidity <90% r.H. non-condensing
Storage temperature -20T70 °C
Storage humidity <90% relative humidity. non-condensing
Front panel degree of protection montaggio a pann. liscio e indeform. con guarniz. IP65
Control pollution status 2 (normal situation)
PTI of the insulating material printed circuit board 250, insulation 175
Period of electric stress across insulating parts long
Heat and fi re resistance category category D and category B (UL 94-V0)
Class of protection against voltage surges category II
Type of disconnection or interruption 1.B relay contacts (micro-disconnection)
Construction of control incorporated control, electronically
Classifi cation according to protection against
electric shock
Class II, by appropriate incorporation
The control is either to be hand-held or is
intented for a hand-held equipment
no
Software class and structure Class A
Front panel cleaning use only neutral detergents and water
Serial interface for CAREL network external, available on all models
Interface for repeater display external, available on IRxxxx(0,L,H)xxxx
Maximum distance between interface and
display
10 m
Programming key available on all models
