pRack +040000071 rel. 1.1 - 14.10.2011 12
ENG
2.2 Pre-confi guration 2: RS3
F1
NO4
NO5
F2
NO7
C1
NO1
ID3
Tsuct Psuct
B3 B1
ID6
NO6
F3
C2
NO2
ID4
C3
NO3
ID5
Tdis
B4
Pcond
B2
Fig. 2.b
Description
3 reciprocating/ scroll compressors
3 fans
1 generic alarm for each compressor
1 generic alarm for condenser
HP/LP pressostats
pRack S, PRK100S**
