pRack +040000071 rel. 1.1 - 14.10.2011 26
ENG
2.9 Pre-confi guration 9: SW1
C1
NO1
NO2
NO7
NO12
ID3
ID4
F1
NO3
NO4
F2
NO5
Tsuct Psuct
B3 B1
ID5
Tdis
B4
Pcond
B2
Text
B5
Fig. 2.i
Description
1 screw compressor with continuous modulation
- 2 pulsing capacity valves
- 2 relays for start up
2 fan stages
2 alarms for each compressor: generic, oil warning
1 generic alarm for condenser
HP/LP pressostats
pRack S, PRK100S**
