Carel pRack PR100 User Manual

pRack +040000071 rel. 1.1 - 14.10.2011 14
ENG
2.3 Pre-confi guration 3: RS3p
Y1
ID10
NO7
ID9
F
NO8
C1
NO1
NO2
ID3
ID4
Tsuct Psuct
B3 B1
C2
NO3
NO4
ID5
ID6
C3
NO5
NO6
ID7
ID8
Tdis
B4
Pcond
B2
Text
B5
Fig. 2.c
Description
3 reciprocating compressors with one unloader each
1 fan stage with inverter
2 alarms for each compressor: thermal overload, oil
1 generic alarm for condenser
HP/LP pressostats
pRack M, PRK100M*
