pRack +040000071 rel. 1.1 - 14.10.2011 30
ENG
2.11 Pre-confi guration 11: d-RS2
Text
B7
C1_L2
NO6
ID8
T suct Psuct
B6 B3
NO7
ID9
C2_L2
F1
NO3
NO4
F2
ID5
NO5
Tdis
B5
Pcond
B2
L1 L2
C1_L1
NO1
ID3
T suct Psuct
B4 B1
NO2
ID4
C2_L1
Fig. 2.k
Description
Double suction line
2 reciprocating/ scroll compressors for each line
2 fans
1 generic alarm for each compressor
1 generic alarm for condenser
HP/LP1/LP2 pressostats
pRack M, PRK100M*
