Carel pRack PR100

43
Mask index Display description Description Default UOM Values
Aa72 (display only)
Err.code Type of error in envelope defi nition --- ---
No error Env. def. inconsist.
Al.code Type of alarm activated --- ---
No Alarm Max time elapsed Zone not allowed Max. no. of restarts
Envel.def.error code Type of error in selection of predefi ned envelope --- ---
No error Comp. not supported Gas type not allowed
Aaan (display only)
Reg.var. Control variable value for generic stage function 1 --- … …(**) Enable Enabling variable status for generic stage function 1 --- --- Not active / active Setpoint Control set point for generic stage function 1 --- … …(**) Diff erential Control diff erential for generic stage function 1 --- … …(**) Mode Control mode for generic stage function 1 (direct or reverse) --- --- D, R Status Status of generic stage function 1 --- --- Not active / active
… … … ……… Aaar (display only)
Reg.var. Control variable value for the generic stage function 5 --- … …(**) Enable Enabling variable status for the generic stage function 5 --- --- Not active / active Setpoint Control set point for the generic stage function 5 --- … …(**) Diff erential Control diff erential for the generic stage function 5 --- … …(**) Mode Control mode for the generic stage function 5 (direct or reverse) --- --- D, R Status Status of generic stage function 5 --- --- Not active / active
Aaas (display only)
Reg.variable Control variable value for generic modulating function 1 --- … …(**) Enable Enabling variable status for generic modulating function 1 --- --- Not active / active Setpoint Control set point for generic modulating function 1 --- … …(**) Diff erential Control diff erential for generic modulating function 1 --- … …(**) Mode Control mode for generic modulating function 1 (direct or reverse) --- --- D, R Status Status of generic modulating function 1 --- % 0.0…100.0
Aaat (display only)
Reg.variable Control variable value for generic modulating function 2 --- … …(**) Enable Enabling variable status for generic modulating function 2 --- --- Not active / active Setpoint Control set point for generic modulating function 2 --- … …(**) Diff erential Control diff erential for generic modulating function 2 --- … …(**) Mode Control mode for generic modulating function 2 (direct or reverse) --- --- D, R Status Status of generic modulating function 2 --- % 0.0…100.0
Aaau (display only)
Reg.variable Control variable status for generic alarm function 1 --- --- Not active / active Enable Enabling variable status for generic alarm function 1 --- --- Not active / active Type Type of alarm for generic alarm function 1 --- --- Light / Serious Delay time Control diff erential for generic alarm function 1 --- s 0…9999 Status Status of generic alarm function 1 --- --- Not active / active
Aaav (display only)
Reg.variable Control variable status for generic alarm function 2 --- --- Not active / active Enable Enabling variable status for generic alarm function 2 --- --- Not active / active Type Type of alarm for generic alarm function 2 --- --- Light / Serious Delay time Control diff erential for generic alarm function 2 --- s 0…9999 Status Status of generic alarm function 2 --- --- Not active / active
