44
Mask index Display description Description Default UOM Values
Aaaw (display only)
Weekday Day of the week --- --- Monday, …, Sunday
TB1: --:-- -> --:--
Enabling and defi nition of time band 1: start hour and minutes, end hour
and minutes for the generic scheduling function
--- … …
…… ………
TB4: --:-- -> --:--
Enabling and defi nition of time band 4: start hour and minutes, end hour
and minutes for the generic scheduling function
--- … …
Status Status of generic scheduling function --- --- Not active / active
Aaax (display only)
Status Status of heat recovery function (line 1) --- --- OFF / ON
Heat recl. temp. Heat recovery temperature (line 1) --- … …(**)
An.OUT modulat. Status of modulating heat recovery valve output (line 1) --- --- 0.0…100.0
HR Prevent Status of prevention via heat recovery (line 1) --- --- OFF / ON
Aaay (display only)
Status Status of heat recovery function (line 2) --- --- OFF / ON
Heat recl. temp. Heat recovery temperature (line 2) --- … …(**)
An.OUT modulat. Status of modulating heat recovery valve output (line 2)
--- --- 0.0…100.0
HR Prevent Status of prevention via heat recovery (line 2) --- --- OFF / ON
Aaaz (display only)
Status Status of ChillBooster device (line 1) --- --- OFF / ON
Ext.temp. Outside temperature (line 1) --- … …(**)
Ext.temp.thr. ChillBooster activation threshold (line 1) --- … …(**)
Time fan 100%
Number of minutes elapsed with fans at 100/number of minutes allowed
(line 1)
--- min 0…999/0…999
Aaa1 (display only)
Status Status of ChillBooster device (line 2) --- --- OFF / ON
Ext.temp. Outside temperature (line 2) --- … …(**)
Ext.temp.thr. ChillBooster activation threshold (line 2) --- … …(**)
Time fan 100%
Number of minutes elapsed with fans at 100/number of minutes allowed
(line 1)
--- min 0…999/0…999
Aaa2 (display only)
Cond.temp. Saturated condensing temperature (line 1) --- … …(**)
Liquid Temp. Liquid temperature (line 1) --- … …(**)
Subcooling Subcooling (line 1) --- … …(**)
Status Status of subcooling function (line 1) --- --- Open / Closed
Aaa3 (display only)
Cond.temp. Saturated condensing temperature (line 2) --- … …(**)
Liquid Temp. Liquid temperature (line 2) --- … …(**)
Subcooling Subcooling (line 2) --- … …(**)
Status Status of subcooling function (line 2) --- --- Open / Closed
Ab01 (display only)
User setp.
User-defi ned set point for suction pressure control, proportional control
(line 1)
--- … …(**)
Actual.setpoint
Eff ective set point for suction pressure control, proportional control (with
compensation applied, line 1)
--- … …(**)
Diff . Suction pressure control diff erential, proportional control (line 1) --- … …(**)
