Carel pRack PR100

47
Mask index Display Description Description Default UOM Values
B.Ingr./Usc. (the I/Os available depend on the selected confi guration, the following are just some examples. For the complete list of I/O positions available see Appendix A.5)
Baa02
DI Alarm 1 for compressor 1 DI position (line 1) 03 --- ---, 01…18, B1…B10 (****) Status (display only) Status of alarm 1 for compressor 1 DI (line 1) --- --- Chiuso / Aperto Logic Logic of alarm 1 for compressor 1 DI (line 1) NC --- NC / NO Function (display only) Alarm 1 for compressor 1 function status (line 1) --- --- Not active / active
…… … ……… Bab01 --- Suction pressure probe position (line1) B1 --- ---, B1…B10 (****) Bab01
--- Suct pressure probe type (line 1)
4...20mA ---
---- 0-1V - 0-10V- 4...20mA- 0-5V
--- (display only) Suction pressure value (line 1) --- … …(**) Upper value Suct pressure maximum value (line 1) 7.0 barg … …(**) Lower value Suct pressure minimum value (line 1) -0,5 barg … …(**) Calibration Suction pressure probe adjustment (line 1) 0.0 barg … …(**)
…… … ……… Bac02
Line relay DO Compressor 1 line DO position and status (On/Off ) display (line 1) … --- ---, 01…29 (****) Part winding DO/Star relay DO (*)
Compressor 1 part winding or star DO position and status (On/Off ) display (line 1)
… --- ---, 01…29 (****)
---/ Delta relay DO (*) Compressor 1 delta DO position and status (On/Off ) display (line 1) … --- ---, 01…29 (****)
Bac03
DO Compressor 1 unloader 1 DO position (line 1) … --- ---, 01…29 (****) Status (display only) Status for compressor 1 unloader 1 DO (line 1)
--- --- Closed / Open
Logic Logic for compressor 1 unloader 1 DO (line 1) NO --- NC / NO Function (display only) Compressor 1 unloader 1 function status (line 1) --- --- Not active / active
…… … ……… Bad01
AO Compressor modulating device AO position (line 1) 0 --- ---, 01…06 (****) Status (display only) Modulating device output value (line 1) 0 % 0.0…100.0
…… … ……… Bb01
Suction L1 Suction line 1 in manual mode DIS --- DIS / AB Suction L2 Suction line 2 in manual mode DIS --- DIS / AB Discharge L1 Condenser line 1 in manual mode DIS --- DIS / AB Discharge L2 Condenser line 2 in manual mode DIS --- DIS / AB Timeout Manual mode duration after last key pressed 10 min 0…500
Bba02
Compressor 1 Force to
Manual stages request for compressor 1 (line 1)
OFF ---
OFF / ON 2 STAGES(*)
3 STAGES (*) 4 STAGES (*)
…… … ……… Bba16
Compressor 12 Force to
Manual stage request for compressor 12 (line 1)
OFF ---
OFF / ON 2 STAGES(*)
3 STAGES (*) 4 STAGES (*)
Bba17
Oil cool pump1 Force to
Manual operating status for oil cooling pump 1 (line 1)
OFF --- OFF / ON
Oil cool pump2 Force to
Manual operating status for oil cooling pump 2 (line 1)
OFF --- OFF / ON
Bba18
Oil cool fan Force to
Manual operating status for oil cooling fan (line 1)
OFF --- OFF / ON
Bba20
Compressor 1 Force to
Manual stage request for compressor 1 (line 2)
OFF ---
OFF / ON 2 STAGES (*)
3 STAGES (*) 4 STAGES (*)
…
…
………
