46
Mask index Display description Description Default UOM Values
Ab08 (display only)
User setp.
User-defi ned set point for condensing pressure control, proportional
control (line 2)
--- … …(**)
Actual setp.
Eff ective set point for condensing pressure control, proportional control
(with compensation applied, line 2)
--- … …(**)
Neutral zone Neutral zone for condensing pressure control (line 2) --- … …(**)
Incr.diff .
Increase diff erential for the condensing pressure control, neutral zone
control (line 2)
--- … …(**)
Decr.diff .
Decrease diff erential for the condensing pressure control, neutral zone
control (line 2)
--- … …(**)
Ab12 Setpoint Setpoint without compensation (suction line 1) 3.5 barg … …(**)
Ab13 Setpoint Setpoint without compensation (condenser line 1) 12.0 barg … …(**)
Ab14 Setpoint Setpoint without compensation (suction line 2) 3.5 barg … …(**)
Ab15 Setpoint Setpoint without compensation (condenser line 2) 12.0 barg … …(**)
Ac01
Status Unit status (display only) Off from keypad ---
Waiting..
Unit On/
Off from alarm
Off from
blackout
Off from BMS
Off by default
Off by default
Off by DIN
Off from
keypad
Manual op.
Prevent HP
--- On-Off from keypad (line 1) OFF --- OFF / ON
Ac02
L1:
L2:
Unit status (display only) Off from keypad --- …(See above Ac01)
--- On-Off from keypad (line 1) OFF --- OFF / ON
--- On-Off from keypad (line 2) OFF --- OFF / ON
Ac03
Enable of unit OnOff
By digit input
Enable unit On/Off from digit input (line 1) NO --- NO / YES
By supervisor Enable unit On/Off from supervisor (line 1) NO --- NO / YES
By black out Enable unit On/Off from black out (line 1) NO --- NO / YES
Ac04
Unit on delay after
blackout
System on delay after black out (line 1) 0 s 0…999
Ac06
Enable of unit OnOff
By digit input
Enable unit On/Off from digit input (line 2) NO --- NO / YES
By supervisor Enable unit On/Off from supervisor (line 2) NO --- NO / YES
By black out Enable unit On/Off from black out (line 2) NO --- NO / YES
Ac07
Unit on delay after
blackout
System on delay after black out (line 2) 0 s 0…999
