Carel pRack PR100

49
Mask index Display Description Description Default UOM Values Bc02
Test Aout Enable AO test mode NO --- NO / SI Timeout Test mode duration after last button pressed 10 min 0…500
Bca10
DO1 DO 1 logic for test NO --- NO / NC
DO 1 value for test OFF --- OFF/ ON
…… … ……… Bca26
DO29 DO 29 logic for test NO --- NO / NC
DO 29 value for test OFF --- OFF / ON
Bcb10 AO1 AO 1 value for test 0.0 --- 0.0…100.0 …… ……… Bcb12 AO6 AO 6 value for test 0.0 --- 0.0…100.0 Mask index Display Description Description Default UOM Values
C.Compressors (*) (The I/Os available depend on the selected confi guration, the following are just some examples. For the complete list of I/O positions available see
Appendix A.5) Caa01
DI Alarm 1 for compressor 1 DI position (line 1) 03 --- ---, 01…18, B1…B10 (****) Status (display only) Status of alarm 1 for compressor 1 DI (line 1) --- --- Closed / Open Logic Logic of alarm 1 for compressor 1 DI (line 1) NC --- NC / NO Function (display only) Alarm 1 for compressor 1 function status (line 1) --- --- Not active / active
…… … ……… Caa08
Line relay DO Compressor 1 part winding or star DO position and status (On/Off )
display (line 1)
… --- ---, 01…29 (****)
Part winding DO/Star relay DO (*)
Compressor 1 delta DO position and status (On/Off ) display (line 1)
… --- ---, 01…29 (****)
---/ Delta relay DO (*) Compressor 1 line DO position and status (On/Off ) display (line 1) … --- ---, 01…29 (****)
Caa09
DO Unloader 1 for compressor 1 DO position (line 1) … --- ---, 01…29 (****) Status (display only) Status of unloader 1 for compressor 1 DI (line 1) --- --- Closed / Open Logic Logic of unloader 1 for compressor 1 DI (line 1) NC --- NC / NO Function (display only) Unloader 1 for compressor 1 function status (line 1) --- --- Not active / active
…… … ……… Caa14
AO Compressor modulating device AO position (line 1) 0 --- ---, 01…06 (****) Status (display only) Modulating device output value (line 1) 0 % 0.0…100.0
…… … ……… Caaal
--- Suction pressure probe position (line1) B1 --- ---, B1…B10 (****) --- Suct pressure probe type (line 1)
4...20mA ---
---- 0-1V 0-10V 4...20mA 0-5V
--- (display only) Suction temperature value (line 1) --- … …(**) Upper value Suct pressure maximum limit (line 1) 7.0 barg … …(**) Lower value Suct pressure minimum limit (line 1) -0,5 barg … …(**) Calibration Suction pressure probe adjustment (line 1) 0.0 barg … …(**)
…… … ………
