51
Mask index Display Description Description Default UOM Values
Cad04
Activ.Time Bands Day of the week
LUN, MAR, ...DOM
TB1: --:-- -> --:-- Time band 1 enabling and defi nition: start hour and minute, end hour
and minute (suction line 1)
--- … …
…… ………
TB4: --:-- -> --:-- Time band 4 enabling and defi nition: start hour and minute, end hour
and minute (suction line 1)
--- … …
Changes Time band change action
--- ---
---
CONFIRM&SAVE
LOAD PREVIOUS
CLEAR ALL
Copy to Copy settings to other days
0 ---
MONDAY…SUNDAY; MON-FRI;
MON-SAT; SAT&SUN; ALL DAYS
Cad05 Change set by DI Enable setpoint compensation by digital input (suct/cond line 1) NO --- NO / YES
Cad06
--- Position of the probe for suction pressure setpoint compensation (line1) --- --- ---, B1…B10 (****)
--- Type of the probe for suction pressure setpoint compensation (line1)
4...20mA ---
----
0-1V - 0-10V- 4...20mA- 0-5V
--- (display only) Compensation value (line 1) --- … -99.9…99.9
max Maximum value of compensation (line 1) --- … -99.9…99.9
min Minimum value of compensation (line 1) --- … -99.9…99.9
Cad08
Enable fl oating suction
setpoint
Enable fl oating setpoint (suction line 1)
NO --- NO / YES
Cad09
Maximum fl oating
setpoint
Max compressor fl oating setpoint settable (line 1)
…(**) … …(**)
Minimum fl oating
setpoint
Minimum compressor fl oating setpoint settable (line 1)
…(**) … …(**)
Cad10
Max.setpoint variation
admitted
Maximum delta admitted for fl oating setpoint (suction line 1)
…(**) … …(**)
Offl ine decreasing time Reduction time when supervisor is offl ine for fl oating setpoint
(suction line 1)
0 min 0…999
Cae01
Number of alarms for
each compressor
Number of alarms for each compressor (line 1)
1/4 (*) --- 0…4/7 (*)
Cae02
Alarm1 description Selection of the fi rst compressor alarm description: Generic, Overload,
High pressure, Low pressure, Oil (line 1)
… ---
(Not available)
(Not selected)
(Selected)
Cae03
Alarm1 description (*) Selection of the fi rst compressor alarm description: Rotation, Oil warning
(line 1)
… ---
(Not available)
(Not selected)
(Selected)
Cae04
Activ.delay Activation delay for compressor alarm 1 during working (line 1) 0 s 0…999
Start up delay Activation delay for compressor alarm 1 at start up (line 1) 0 s 0…999
Reset Type of reset for compressor alarm 1 (line 1) AUT. --- AUT. / MAN.
Priority Type of priority for compressor alarm 1 (line 1) GRAVE --- Light / Serious
…… … ………
Cae24
Suction pressure/tempe-
rature high alarm
Type of high suction pressure/temperature alarm threshold
ASSOLUTO --- ABSOLUTE / RELATIVE
Threshold High suction pressure/temperature alarm threshold …(**) … …(**)
