55
Mask index Display Description Description Default UOM Values
Caf91
S1 Enable size and size for compressor group 1 (line 1) Si
10.0
---
kW
NO/SI
0.0…500.0
…… ………
S4 Enable size and size for compressor group 4 (line 1)
NO
---
---
kW
---
NO/SI
0.0…500.0
Caf92
S1 Enable stages and stages for compressor group 1 (line 1)
Si
100
---
%
NO/SI
100; 50/100; 50/75/100;
25/50/75/100; 33/66/100
…… ………
S4 Enable stages and stages for compressor group 4 (line 1)) NO
---
---
kW
NO/SI
S1…S4
Caf93
C01 Size group for compressor 1 (line 1) or presence of inverter S1 --- S1…S4/INV
…… ………
C12 Size group for compressor 6 (line 1) S1 --- S1…S4
Caf95
Min on time Minimum Digital Scroll
TM
compressor On time (line 1) 60 s 0…999
Min off time Minimum Digital Scroll
TM
compressor Off time(line 1) 180 s 0…999
Min time to start same
compressor
Minimum time between starts for Digital Scroll
TM
compressor (line 1)
360 s 0…999
Reactivate start-up
procedure after
Digital Scroll
TM
compressor start-up procedure reactivation time (line 1)
480 min 0…9999
Cag01
Minimum voltage Voltage corresponding to the minimum capacity of the inverter (line 1) 0.0 V 0.0…10.0
Maximum voltage Voltage corresponding to the maximum capacity of the inverter (line 1) 10.0 V 0.0…10.0
Nominal freq. Nominal frequency (nominal capacity at nominal frequency) (line 1) 50 Hz 0…150
Nominal power Nominal capacity for compressor managed by inverter at nominal
frequency (line 1)
10.0 Kw 0.0…500.0
Cag02
Rising time Time to pass from min capacity to max capacity for modulating device
(line 1)
90 s 0…600
Falling time Time to pass from max capacity to min capacity for modulating device
(line 1)
30 s 0…600
Cag03
Enable compressor mo-
dulation inside neutral
zone
Enable compressor 1 modulation inside Neutral zone (line 1)
SI --- NO / YES
Cag04
Enable suction press.
backup probe
Enable screens for suction pressure backup probe confi guration (line 1)
NO --- NO / YES
Cag05
Request in case of regu-
lat.probe fault
Compressor forcing value in case of suction probes fault (line 1)
50.0 % 0.0…100.0
Cag06
Enable anti liquid return
valve
Enable liquid non return function (line 1)
NO --- NO / YES
Cag07
Enable compressor enve-
lop management (*)
Enable compressor envelope management (screw only).
For details on confi guration contact Carel.
NO --- NO / YES
The following parameters refer to line 2, for details see the corresponding parameters for line 1 above
