Carel pRack PR100

56
Mask index Display Description Description Default UOM Values Cba01
DI Alarm 1 for compressor 1 DI position (line 2) 03 --- ---, 01…18, B1…B10 (****) Status (display only) Status of alarm 1 for compressor 1 DI (line 2) --- --- Closed / Open Logic Logic of alarm 1 for compressor 1 DI (line 2)
NC ---
NC NO
Function (display only) Alarm 1 for compressor 1 function status (line 2) --- --- Not active / active
…… … ……… Cbb01
Regulation by Compressor control by temperature or pressure (line 2) PRESSURE --- PRESSIONE TEMPERATURA Regulation type Compressor control type (line 2)
Neutral zone ---
Proportional band Neutral zone
…… … ……… Cbc01
Working hours Compressor 1
Compressor 1 max operating hours (line 2)
--- --- 0…999999
…… … ……… Cbd01
Enable suction setpoint compensation
Enable setpoint compensation (suction line 2)
NO --- NO / YES
Enable compensation by analog IN
Enable setpoint compensation by probe (suction line 2)
NO --- NO / YES
…… … ……… Cbe01
Number of alarms for each compressor
Number of alarms for each compressor (line 2)
1 --- 0…4
…… … ……… Cbf02
Compressors type Type of compressors (line 2) RECIPROCATING --- RECIPROCATING / Scroll
Compressors number Number of compressors (line 2) 2/3 (*) --- 1…12
…… … ……… Cbg01
Minimum voltage Voltage corresponding at the minimum capacity of the inverter (line 2) 0.0 Hz 0.0…10.0 Maximum voltage Voltage corresponding at the maximum capacity of the inverter (line 2) 10.0 Hz 0.0…10.0 Nominal freq. Nominal frequency (nominal capacity at nominal frequency) (line 2) 50 Hz 0…150 Nominal power Nominal capacity for compressor managed by inverter at nominal
frequency (line 2)
10.0 Kw 0.0…500.0
…… … ………
Mask index Display Description Description Default UOM Values
D.Condensers (The I/Os available depend on the selected confi guration, the following are just some examples. For the complete list of I/O positions available see Appen-
dix A.5) Daa01
DI Fan 1 overload DI position (line 1) … --- ---, 01…18, B1…B10 (****) Status (display only) Status of fan 1 overload DI (line 1)
--- ---
Closed Open
Logic Logic of fan 1 overload DI (line 1) NC --- NC / NO Function (display only) Fan 1 overload function status (line 1)
--- ---
Not active Active
…… … ………
