58
Mask index Display Description Description Default UOM Values
Dab15
Power unload to 0%
min time
Minimum time to decrease capacity request to 0%, Neutral zone control
(condenser line 1)
30 s 0…9999
Power unload to 0%
max time
Maximum time to decrease capacity request to 0%, Neutral zone control
(condenser line 1)
180 s 0…9999
Dad01
Enable condensing
setpoint compensation
Enable setpoint compensation (condenser line 1)
NO --- NO / YES
Dad02
Winter off set Enable setpoint compensation (condenser line 1) 0.0 … -999,9…999,9
Closing off set Off set applied for Winter period 0.0 … -999,9…999,9
Dad03
Enable setpoint compen-
sation by scheduler
Enable scheduler setpoint compensation (condenser line 1)
NO --- NO / YES
Dad04
Activ.Time Bands Day of the week --- --- MON, ...SUN
TB1: --:-- -> --:-- Time band 1 enabling and defi nition: start hour and minute, end hour
and minute (suction line 1)
--- … …
…… ………
TB4: --:-- -> --:-- Time band 4 enabling and defi nition: start hour and minute, end hour
and minute (suction line 1)
--- … …
Changes Time band changes action
--- ---
---
CONFIRM&SAVE
LOAD PREVIOUS
CLEAR ALL
Copy to Copy settings to other days
0 ---
MONDAY…SUNDAY; MON-FRI;
MON-SAT; SAT&SUN; ALL DAYS
Dad05
Enable fl oating conden-
sing setpoint
Enable fl oating setpoint (condenser line 1)
NO --- NO/ YES
Dad06
Off set for external tem-
perature
Temperature delta for fl oating setpoint (condenser line 1)
0.0 … -9,9…9,9
Controlled by:
-Digital input
Enable fl oating condensing from digital input
NO --- NO / YES
Dad07
Change set by digital
input
Enable setpoint compensation by digital input (suction/condensing
line 1)
NO --- NO / YES
Dae01
Cond.pressure/tempera-
ture high alarm
Type of high condensing pressure/temperature alarm threshold (line 1)
ABSOLUTE --- ABSOLUTE / RELATIVE
Threshold High condensing pressure/temperature alarm threshold (line 1) 24.0 barg … …(**)
Dae02
Cond.pressure/tempera-
ture alarm diff .
High condensing pressure/temperature alarm diff erential (line 1)
1.0 barg … …(**)
Alarm delay High condensing pressure/temperature alarm delay (line 1) 60 s 0…999
Dae03
Cond.pressure/tempera-
ture low alarm
Type of low condensing pressure/temperature alarm threshold
(line 1)
ABSOLUTE --- ABSOLUTE / RELATIVE
Threshold Low condensing pressure/temperature alarm threshold (line 1) 7.0 barg … …(**)
Dae04
Cond.pressure/tempera-
ture alarm diff .
Low condensing pressure/temperature alarm diff erential (line 1)
1.0 barg … …(**)
Alarm delay Low condensing pressure/temperature alarm delay (line 1) 30 s 0…999
Dae05
Common fan overload Common fan overload (line 1) YES --- NO / YES
Delay Common fan overload alarm activation delay AUTOMATIC --- AUTOMATIC
MANUAL
Reset Type of common fan overload alarm reset 0 s 0…500
