Mask index Display Description Description Default UOM Values
Daf01 Number of present fans Number of fans (line 1) 3 --- 0…16
Daf02 Fan1, Fan2, … Enable fans 1 to 12 (line 1) AB --- DIS / AB
Daf03 Fan13, Fan14, … Enable fans 13 to 16 (line 1) AB --- DIS / AB
Daf04
Refrigerant type Type of refrigerant (condenser line 1)
R404A ---
R22 - R134a - R404A - R407C
- R410A - R507A - R290 - R600
- R600a - R717 - R744 - R728 -
R1270 - R417A - R422D
Daf05
Devices rotation type Type of rotation devices (condenser line 1)
FIFO ---
------
FIFO
LIFO
TEMPO
CUSTOM
Daf07, Daf08
Custom rotation
Switch ON order
Switch ON order for fans with custom rotation (condenser line 1)
1 --- 1…16
Daf09, Daf10
Custom rotation
Switch OFF order
Switch OFF order for fans with custom rotation (condenser line 1)
1 --- 1…16
Dag01
Modulate speed device Fan driver type (line 1) NONE --- NONE
INVETER
PHASE CONTROL
Dag02
Neutral zone reg. Fan control also inside Neutral zone (line 1) NO --- NO / YES
Min.out value Minimum voltage for compressor inverter (line 1) 0.0 V 0.0…9,9
Max.out value Maximum voltage for compressor inverter (line 1) 10.0 V 0.0…99,9
Min. power refer. Minimum capacity of fan modulating device (line 1) 60 % 0…100
Max. power refer. Maximum capacity of fan modulating device (line 1) 100 % 0…999
Dag03
Rising time Time to pass from min capacity to max capacity for fan modulating
device (line 1)
1200 s 0…32000
Falling time Time to pass from max capacity to min capacity for fan modulating
device (line 1)
1200 s 0…32000
Num.control.fans Number of fans under inverter (only for alarm enabling) 1 --- 0…16
Dag04
Split Condenser Enable split condenser (line 1) NO --- NO / YES
Controlled by:
-Digital input
Split Condenser controlled by digital input (line 1)
--- --- NO / YES
-External temp. Split Condenser controlled by outside temperature (line 1) --- --- NO / YES
-Scheduler Split Condenser controlled by scheduler (line 1) --- --- NO / YES
Dag05
Est. Temp.Thr. Split condenser by outside temperature management setpoint
(line 1)
10.0 °C … -99,9…99,9
Est. Temp.Diff . Split condenser by outside temperature management diff erential (line 1) 2,5 °C … -99,9…99,9
Dag06
Type Fans enabled with split condenser (line 1) CUSTOM --- CUSTOM
ODD
EVEN
GREATER THAN
LESS THAN
--- Only when enabling type is GREATER THAN or LESS THAN, number of
fans to consider for splitting (line 1)
0 --- 0…16
