60
Mask index Display Description Description Default UOM Values
Dag09
Disable split condenser
as fi rst stage of HP
pressostat
Disable split condenser when high condensing pressure prevent occurs
(line 1) NO --- NO / YES
for Duration of split condenser deactivation for high condensing
pressure prevent (line 1)
0 h 0…24
Dag10
Anti-noise Enable silencer (line 1) DISAB. --- DISABLE / ENABLE
Max output Maximum request allowed when silencer function is active (line 1) 75.0 % % 0.0…100.0
Controlled by:
-Digital input
Silencer controlled by digital input (condenser line 1)
NO --- NO / YES
-Scheduler Silencer controlled by scheduler (condenser line 1) NO --- NO / YES
Dag12
Activ.Time Bands Day of the week --- --- MON, ..., SUN
TB1: --:-- -> --:-- Time band 1 enabling and defi nition: start hour and minute, end hour
and minute (condenser line 1)
--- … …
…… ………
TB4: --:-- -> --:-- Time band 4 enabling and defi nition: start hour and minute, end hour
and minute (condenser line 1)
--- … …
Changes Time band changes action
--- ---
---
CONFIRM&SAVE
LOAD PREVIOUS
CLEAR ALL
Copy to Copy settings to other days
0 ---
MONDAY…SUNDAY; MON-FRI;
MON-SAT; SAT&SUN; ALL DAYS
Dag13
Speed Up Enable speed up (condenser line 1) YES --- NO / YES
Speed Up time Speed up time (condenser line 1) 5 s 0…60
Ext.Temp.Manage Enable speed up management by outside temperature (conden. line 1) DIS --- DIS / AB
Ext.Temp.Thresh. Outside temperature threshold for speed up management
(condenser line 1)
25.0 °C … -99,9…99,9
Ext.Temp.Diff . Outside temperature diff erential for speed up management
(condenser line 1)
2,5 °C … -99,9…99,9
Dag14
Enable condensing press.
backup probe
Enable the screens for condensing pressure backup probe
confi guration (condenser line 1)
NO --- NO / YES
Dag15
Request in case of egulat.
probes fault
Value of fans forcing in case of condensing probes fault (line 1)
50.0 % 0.0…100.0
The following parameters refer to line 2, for details see the corresponding parameters for line 1 above
Dba01
DI Fan 1 overload DI position (line 2) … --- ---, 01…18, B1…B10 (****)
Status (display only) Status of fan 1 overload DI (line 2) --- --- Closed / Open
Logic Logic of fan 1 overload DI (line 2) NC --- NC / NO
Function (display only) Fan 1 overload function status (line 2) --- --- Not active / active
…… … ………
Dbb01
Regulation by Condenser control by temperature or pressure (line 2) PRESSURE --- PRESSURE TEMPERATURE
Regulation type Condenser control type (line 2) PROPORTIONAL
BAND
---
Proportional band
Neutral zone
…… … ………
