Carel pRack PR100

pRack +040000071 rel. 1.1 - 14.10.2011
9
ENG
Wizard Ib43
Compressor config.
Configure another
suction line:
YES
Fig. 1.h
To the next question, which prompts if there is a pRack
board dedicated to the second line, answer YES; in this
way, the pRack PR100 software prepares to confi gure
the board with address 2 in the pLAN:
Wizard Ib45
Compressor config.
Dedicated pRack
board for
suction line:
YES
Fig. 1.i
After having answered the questions for the
confi guration of the second suction line, the software
then asks if there is a pLAN board dedicated to
condenser line 1. In the case shown in the example,
answer NO.
Wizard Ib90
Compressor config.
Dedicated pRack
board for
suction line:
NO
Fig. 1.j
After having confi gured condenser line 1, the software
asks if condenser line 2 is used; answer YES:
Wizard Ib96
Configure another
condensing line:
YES
Fig. 1.k
After having also confi gured the second condenser line,
the software asks if a summary should be displayed of
the settings made:
Wizard Ib2a
Visualize Wizard
report:
NO
(Push (DOWN)
to continue)
Fig. 1.l
If the settings are correct, the set values can be installed:
Wizard Ib3a
Board necessary
All boards prsent
(ENTER) to continue
1
2
Fig. 1.m
After waiting a few seconds, the unit can be started.
Wizard
Successfully complete
Press (ENTER) to
continue
Fig. 1.n
Note: after having confi gured pRack PR100, the
device needs to be switched off and on again to
permanently save the new data.
