2.2.11 Meaning of the inputs/outputs on the pRack pR300 S, M, L boards
Version Connector Signal Description
S, M, L
J1-1 G +24 Vdc or 24 Vac power supply
J1-2 G0 power supply reference
J2-1 B1 universal analogue input 1 (NTC, 0 to 1 V, 0 to 5 V ratiometric, 0…10 V, 0…20 mA, 4…20 mA)
J2-2 B2 universal analogue input 2 (NTC, 0 to 1 V, 0 to 5 V ratiometric, 0…10 V, 0…20 mA, 4…20 mA)
J2-3 B3 universal analogue input 3 (NTC, 0 to 1 V, 0 to 5 V ratiometric, 0…10 V, 0…20 mA, 4…20 mA)
J2-4 GND common for analogue inputs
J2-5 +VDC 21 Vdc power supply for active probes (maximum current 200 mA)
J3-1 B4 passive analogue input 4 (NTC, PT1000, ON/OFF)
J3-2 BC4 common for analogue input 4
J3-3 B5 passive analogue input 5 (NTC, PT1000, ON/OFF)
J3-4 BC5 common for analogue input 5
J4-1 VG power to optically-isolated analogue output, 24 Vac/Vdc
J4-2 VG0 power to optically-isolated analogue output, 0 Vac/Vdc
J4-3 Y1 analogue output no. 1, 0…10 V
J4-4 Y2 analogue output no. 2, 0…10 V
J4-5 Y3 analogue output no. 3, 0…10 V
J4-6 Y4 analogue output no. 4, 0…10 V
J5-1 ID1 digital input no. 1, 24 Vac/Vdc
J5-2 ID2 digital input no. 2, 24 Vac/Vdc
J5-3 ID3 digital input no. 3, 24 Vac/Vdc
J5-4 ID4 digital input no. 4, 24 Vac/Vdc
J5-5 ID5 digital input no. 5, 24 Vac/Vdc
J5-6 ID6 digital input no. 6, 24 Vac/Vdc
J5-7 ID7 digital input no. 7, 24 Vac/Vdc
J5-8 ID8 digital input no. 8, 24 Vac/Vdc
J5-9 IDC1 common for digital inputs from 1 to 8 (negative pole for DC power supply)
M, L
J6-1 B6 universal analogue input 6 (NTC, 0 to 1 V, 0 to 5 V ratiometric, 0…10 V, 0…20 mA, 4…20 mA)
J6-2 B7 universal analogue input 7 (NTC, 0 to 1 V, 0 to 5 V ratiometric, 0…10 V, 0…20 mA, 4…20 mA)
J6-3 B8 universal analogue input 8 (NTC, 0 to 1 V, 0 to 5 V ratiometric, 0…10 V, 0…20 mA, 4…20 mA)
J6-4 GND common for analogue inputs
J7-1 ID9 digital input no. 9, 24 Vac/Vdc
J7-2 ID10 digital input no. 10, 24 Vac/Vdc
J7-3 ID11 digital input no. 11, 24 Vac/Vdc
J7-4 ID12 digital input no. 12, 24 Vac/Vdc
J7-5 IDC9 common for digital inputs from 9 to 12 (negative pole for DC power supply)
J8-1 ID13H digital input no. 13, 230 Vac
J8-2 ID13 digital input no. 13, 24 Vac/Vdc
J8-3 IDC13 common for digital inputs 13 and 14 (negative pole for DC power supply)
J8-4 ID14 digital input no. 14, 24 Vac/Vdc
J8-5 ID14H digital input no. 14, 230 Vac
S, M, L
J9 8-pin telephone connector for connecting a display terminal (not used)
J10 6-pin telephone connector for connecting the standard pGDE user terminal
J11-1 RX-/TX- RX-/TX- connector for RS485 connection to the pLAN network
J11-2 RX+/TX+ RX+/TX+ connector for RS485 connection to the pLAN network
J11-3 GND GND connector for RS485 connection to the pLAN network
J12-1 C1 common for relays: 1, 2, 3
J12-2 NO1 normally open contact, relay no. 1
J12-3 NO2 normally open contact, relay no. 2
J12-4 NO3 normally open contact, relay no. 3
J12-5 C1 common for relays: 1, 2, 3
J13-1 C4 common for relays: 4, 5, 6
J13-2 NO4 normally open contact, relay no. 4
J13-3 NO5 normally open contact, relay no. 5
J13-4 NO6 normally open contact, relay no. 6
J13-5 C4 common for relays: 4, 5, 6
J14-1 C7 common for relay no. 7
J14-2 NO7 normally open contact, relay no. 7/ normally open contact, relay no. 7 SSR 24 Vac/Vdc (*)
J14-3 C7 common for relay no. 7
J15-1 NO8 normally open contact, relay no. 8/ only S-board: normally open contact, relay no. 8 SSR 24 Vac/Vdc, S board only (*)
J15-2 C8 common for relay no. 8
J15-3 NC8/--- normally closed contact relay no. 8/ only S-board: not used, S board only (*)
M, L
J16-1 C9 common for relay: 9, 10, 11
J16-2 NO9 normally open contact, relay no. 9
J16-3 NO10 normally open contact, relay no. 10
J16-4 NO11 normally open contact, relay no. 11
J16-5 C9 common for relay: 9, 10, 11
J17-1 NO12 normally open contact, relay no. 12/ normally open contact, relay no. 12 SSR 24 Vac/Vdc (*)
J17-2 C12 common for relay no. 12
J17-3 NC12/--- normally closed contact relay no. 12/ not used (*)
J18-1 NO13 normally open contact, relay no. 13 / normally open contact, relay no. 13 SSR 24 Vac/Vdc (*)
J18-2 C13 common for relay no. 13
J18-3 NC13 normally closed contact relay no. 13 / not used (*)
L
J19-1 ID15H digital input no. 15, 230 Vac
J19-2 ID15 digital input no. 15, 24 Vac/Vdc
J19-3 IDC15 common for digital inputs 15 and 16 (negative pole for DC power supply)
J19-4 ID16 digital input no. 16, 24 Vac/Vdc
J19-5 ID16H digital input no. 16, 230 Vac
J20-1 Y5 digital input no. 5 0…10 V
J20-2 Y6 digital input no. 6 0…10 V
J20-3 B9 passive analogue input 9 (NTC, PT1000, ON/OFF)
J20-4 BC9 common for analogue input 9
J20-5 B10 passive analogue input 10 (NTC, PT1000, ON/OFF)
