pRack +0300025EN rel. 1.3 - 17.12.2015
A.5 I/O Table
Digital inputs
Mask Index Description Chan. Logic Notes
Line 1
Suction
Ac05, Baack Unit ON/OFF line 1
Baa56, Caaah Common low pressure switch line 1
Baada, Caa14 Compressor inverter warning
Baa02, Caa01 Alarm 1 compressor 1 line 1
Baa03, Caa02 Alarm 2 compressor 1 line 1
Baa04, Caa03 Alarm 3 compressor 1 line 1
Baa05, Caa04 Alarm 4 compressor 1 line 1
Baa06, Caa05 Alarm 5 compressor 1 line 1
Baa07, Caa06 Alarm 6 compressor 1 line 1
Baa08. Caa07 Alarm 7 compressor 1 line 1
Baa09, Caa15 Alarm 1 compressor 2 line 1
Baa10, Caa16 Alarm 2 compressor 2 line 1
Baa11, Caa17 Alarm 3 compressor 2 line 1
Baa12, Caa18 Alarm 4 compressor 2 line 1
Baa13, Caa19 Alarm 5 compressor 2 line 1
Baa14, Caa20 Alarm 6 compressor 2 line 1
Baa15, Caa21 Alarm 7 compressor 2 line 1
Baa17, Caa28 Alarm 1 compressor 3 line 1
Baa18, Caa29 Alarm 2 compressor 3 line 1
Baa19, Caa30 Alarm 3 compressor 3 line 1
Baa20, Caa31 Alarm 4 compressor 3 line 1
Baa21, Caa32 Alarm 5 compressor 3 line 1
Baa22, Caa33 Alarm 6 compressor 3 line 1
Baa23, Caa34 Alarm 7 compressor 3 line 1
Baa24, Caa40 Alarm 1 compressor 4 line 1
Baa25, Caa41 Alarm 2 compressor 4 line 1
Baa26, Caa42 Alarm 3 compressor 4 line 1
Baa27, Caa43 Alarm 4 compressor 4 line 1
Baa28, Caa44 Alarm 5 compressor 4 line 1
Baa29, Caa45 Alarm 6 compressor 4 line 1
Baa30, Caa46 Alarm 7 compressor 4 line 1
Baa32, Caa53 Alarm 1 compressor 5 line 1
Baa33, Caa54 Alarm 2 compressor 5 line 1
Baa34, Caa55 Alarm 3 compressor 5 line 1
Baa35, Caa56 Alarm 4 compressor 5 line 1
Baa36, Caa57 Alarm 5 compressor 5 line 1
Baa37, Caa58 Alarm 6 compressor 5 line 1
Baa38, Caa59 Alarm 7 compressor 5 line 1
Baa39, Caa65 Alarm 1 compressor 6 line 1
Baa40, Caa66 Alarm 2 compressor 6 line 1
Baa41, Caa67 Alarm 3 compressor 6 line 1
Baa42, Caa68 Alarm 4 compressor 6 line 1
Baa43, Caa69 Alarm 5 compressor 6 line 1
Baa44, Caa70 Alarm 6 compressor 6 line 1
Baa45, Caa71 Alarm 7 compressor 6 line 1
Baa47, Caa78 Alarm 1 compressor 7 line 1
Baa48, Caa79 Alarm 2 compressor 7 line 1
Baa49, Caa84 Alarm 1 compressor 8 line 1
Baa50, Caa85 Alarm 2 compressor 8 line 1
Baa51, Caa90 Alarm 1 compressor 9 line 1
Baa52, Caa91 Alarm 2 compressor 9 line 1
Baa53, Caa95 Alarm 1 compressor 10 line 1
Baa54, Caa99 Alarm 1 compressor 11 line 1
Baa55, Caaad Alarm 1 compressor 12 line 1
Baa58, Caaaj Common oil alarm line 1
Baa59, Caaak Liquid level alarm line 1
Condenser
Baadc Fan inverter warning line 1
Baa57 Common high pressure switch line 1
Baaau, Daa01 Fan overload 1 line 1
Baaav, Daa02 Fan overload 2 line 1
Baaaw, Daa03 Fan overload 3 line 1
Baaax, Daa04 Fan overload 4 line 1
Baaay, Daa05 Fan overload 5 line 1
Baaaz, Daa06 Fan overload 6 line 1
Baaba, Daa07 Fan overload 7 line 1
Baabb, Daa08 Fan overload 8 line 1
Baabc, Daa09 Fan overload 9 line 1
Baabd, Daa10 Fan overload 10 line 1
Baabe, Daa11 Fan overload 11 line 1
Baabf, Daa12 Fan overload 12 line 1
Baabg, Daa13 Fan overload 13 line 1
Baabh, Daa14 Fan overload 14 line 1
Baabi, Daa15 Fan overload 15 line 1
Baabj, Daa16 Fan overload 16 line 1
Baabk, Daa17 Common fan overload line 1
Other functions
Baabl Heat recovery line 1
Baacx, Egaa01 ChillBooster fault line 1
Baacz Enable fl oating condensing line 1
Baacl, Caa00, Daa41 Set point compensation line 1
Daa43 Anti noise line 1
Daa44 Split condenser line 1
Daa45 Enable fl oating condensing line 1
Eeaa02 Heat recovery activation line 1
