pRack +0300025EN rel. 1.3 - 17.12.2015
A.4 Alarm table
Code Description Reset Delay Alarm relay Action
ALA01 Discharge temperature probe malfunction Automatic 60s R2 Related functions disabled
ALA02 Condensing pressure probe malfunction Automatic 60s R1 Related functions disabled
ALA03 Outside temperature probe malfunction Automatic 60s R2 Related functions disabled
ALA04 Generic probe malfunction A, PLB1 Automatic 60s R2 Related functions disabled
ALA05 Generic probe malfunction B, PLB1 Automatic 60s R2 Related functions disabled
ALA06 Generic probe malfunction C, PLB1 Automatic 60s R2 Related functions disabled
ALA07 Generic probe malfunction D, PLB1 Automatic 60s R2 Related functions disabled
ALA08 Generic probe malfunction E, PLB1 Automatic 60s R2 Related functions disabled
ALA09 Generic probe malfunction A, PLB2 Automatic 60s R2 Related functions disabled
ALA10 Generic probe malfunction B, PLB2 Automatic 60s R2 Related functions disabled
ALA11 Generic probe malfunction C, PLB2 Automatic 60s R2 Related functions disabled
ALA12 Generic probe malfunction D, PLB2 Automatic 60s R2 Related functions disabled
ALA13 Generic probe malfunction E, PLB2 Automatic 60s R2 Related functions disabled
ALA14 Generic probe malfunction A, PLB3 Automatic 60s R2 Related functions disabled
ALA15 Generic probe malfunction B, PLB3 Automatic 60s R2 Related functions disabled
ALA16 Generic probe malfunction C, PLB3 Automatic 60s R2 Related functions disabled
ALA17 Generic probe malfunction D, PLB3 Automatic 60s R2 Related functions disabled
ALA18 Generic probe malfunction E, PLB3 Automatic 60s R2 Related functions disabled
ALA19 Generic probe malfunction A, PLB4 Automatic 60s R2 Related functions disabled
ALA20 Generic probe malfunction B, PLB4 Automatic 60s R2 Related functions disabled
ALA21 Generic probe malfunction C, PLB4 Automatic 60s R2 Related functions disabled
ALA22 Generic probe malfunction D, PLB4 Automatic 60s R2 Related functions disabled
ALA23 Generic probe malfunction E, PLB4 Automatic 60s R2 Related functions disabled
ALA24 Suction pressure probe malfunction Automatic 60s R1 Related functions disabled
ALA25 Suction temperature probe malfunction Automatic 60s R2 Related functions disabled
ALA26 Room temperature probe malfunction Automatic 60s R2 Related functions disabled
ALA27 Condensing pressure probe malfunction, line 2 Automatic 60s R1 Related functions disabled
ALA28 Discharge temperature probe malfunction, line 2 Automatic 60s R2 Related functions disabled
ALA29 Suction pressure probe malfunction, line 2 Automatic 60s R1 Related functions disabled
ALA30 Suction temperature probe malfunction, line 2 Automatic 60s R2 Related functions disabled
ALA31 Condensing pressure backup probe malfunction Automatic 60s R2 Related functions disabled
ALA32 Condensing pressure backup probe malfunction, line 2 Automatic 60s R2 Related functions disabled
ALA33 Suction pressure backup probe malfunction Automatic 60s R2 Related functions disabled
ALA34 Suction pressure backup probe malfunction, line 2 Automatic 60s R2 Related functions disabled
ALA35 Common oil temperature probe malfunction Automatic 60s R2 Related functions disabled
ALA36 Common oil temperature probe malfunction, line 2 Automatic 60s R2 Related functions disabled
ALA39 Discharge temperature probe malfunction, compressors 1 to 6 Automatic 60s R2 Related functions disabled
ALA40 Discharge temperature probe malfunction, compressors 1 to 6, line 2 Automatic 60s R2 Related functions disabled
ALA41 Oil temperature probe malfunction compressors 1 to 6, line 1 Automatic 60s R2 Related functions disabled
ALA42 Oil temperature probe malfunction compressor 1, line 2 Automatic 60s R2 Related functions disabled
ALB01 Low suction pressure from pressure switch Semiautomatic Settable R1 Shutdown compressor
ALB02 High condensing pressure from pressure switch Manual/automatic Settable R1 Shutdown compressor
ALB03 Low condensing pressure from probe Automatic Settable R1 Force fans to 0%
ALB04 High condensing pressure from probe Automatic Settable R1 Force fans to 100% and compressor stop
ALB05 Liquid level Automatic Settable R2 -
ALB06 Common oil diff erential Automatic Settable R2 -
ALB07 Common fan circuit breaker Automatic Settable Settable -
ALB08 Low suction pressure from pressure switch, line 2 Semiautomatic Settable R1 Shutdown compressors, line 2
ALB09 High condensing pressure from pressure switch, line 2 Manual/automatic Settable R1 Shutdown compressors, line 2
ALB10 Low condensing pressure from probe, line 2 Automatic Settable R1 Force fans to 0%, line 2
ALB11 High condensing pressure from probe, line 2 Automatic Settable R1 Force fans to 100% and stop compres-
sor, line 2
ALB12 Liquid level, line 2 Automatic Settable R2 -
ALB13 Common oil diff erential, line 2 Automatic Settable R2 -
ALB14 Common fan circuit breaker, line 2 Automatic Settable Settable -
ALB15 High suction pressure from probe Automatic Settable R1 -
ALB16 Low suction pressure from probe Automatic Settable R1 -
ALB17 High suction pressure from probe, line 2 Automatic Settable R1 -
ALB18 Low suction pressure from probe, line 2 Automatic Settable R1 -
ALB21 Shutdown to prevent high pressure Manual Settable R1 Shutdown compressor
ALB22 Shutdown to prevent high pressure, line 2 Manual Settable R1 Shutdown compressors, line 2
ALC01 Alarm 1, compressor 1 Manual/automatic Settable Settable Shutdown compressor 1
ALC02 Alarm 2, compressor 1 Manual/automatic Settable Settable Shutdown compressor 1
ALC03 Alarm 3, compressor 1 Manual/automatic Settable Settable Shutdown compressor 1
ALC04 Alarm 4, compressor 1 Manual/automatic Settable Settable Shutdown compressor 1
ALC05 Alarm 5, compressor 1 Manual/automatic Settable Settable Shutdown compressor 1
ALC06 Alarm 6, compressor 1 Manual/automatic Settable Settable Shutdown compressor 1
ALC07 Alarm 7, compressor 1 Manual/automatic Settable Settable Shutdown compressor 1
ALC08 Alarm 1, compressor 2 Manual/automatic Settable Settable Shutdown compressor 2
ALC09 Alarm 2, compressor 2 Manual/automatic Settable Settable Shutdown compressor 2
ALC10 Alarm 3, compressor 2 Manual/automatic Settable Settable Shutdown compressor 2
ALC11 Alarm 4, compressor 2 Manual/automatic Settable Settable Shutdown compressor 2
ALC12 Alarm 5, compressor 2 Manual/automatic Settable Settable Shutdown compressor 2
ALC13 Alarm 6, compressor 2 Manual/automatic Settable Settable Shutdown compressor 2
ALC14 Alarm 7, compressor 2 Manual/automatic Settable Settable Shutdown compressor 2
ALC15 Alarm 1, compressor 3 Manual/automatic Settable Settable Shutdown compressor 3
ALC16 Alarm 2, compressor 3 Manual/automatic Settable Settable Shutdown compressor 3
ALC17 Alarm 3, compressor 3 Manual/automatic Settable Settable Shutdown compressor 3
ALC18 Alarm 4, compressor 3 Manual/automatic Settable Settable Shutdown compressor 3
ALC19 Alarm 5, compressor 3 Manual/automatic Settable Settable Shutdown compressor 3
ALC20 Alarm 6, compressor 3 Manual/automatic Settable Settable Shutdown compressor 3
ALC21 Alarm 7, compressor 3 Manual/automatic Settable Settable Shutdown compressor 3
ALC22 Alarm 1, compressor 4 Manual/automatic Settable Settable Shutdown compressor 4
ALC23 Alarm 2, compressor 4 Manual/automatic Settable Settable Shutdown compressor 4
ALC24 Alarm 3, compressor 4 Manual/automatic Settable Settable Shutdown compressor 4
ALC25 Alarm 4, compressor 4 Manual/automatic Settable Settable Shutdown compressor 4
ALC26 Alarm 5, compressor 4 Manual/automatic Settable Settable Shutdown compressor 4
ALC27 Alarm 6, compressor 4 Manual/automatic Settable Settable Shutdown compressor 4
ALC28 Alarm 7, compressor 4 Manual/automatic Settable Settable Shutdown compressor 5
ALC29 Alarm 1, compressor 5 Manual/automatic Settable Settable Shutdown compressor 5
