pRack +0300025EN rel. 1.3 - 17.12.2015
Code Description Reset Delay Alarm relay Action
ALC30 Alarm 2, compressor 5 Manual/automatic Settable Settable Shutdown compressor 5
ALC31 Alarm 3, compressor 5 Manual/automatic Settable Settable Shutdown compressor 5
ALC32 Alarm 4, compressor 5 Manual/automatic Settable Settable Shutdown compressor 5
ALC33 Alarm 6, compressor 5 Manual/automatic Settable Settable Shutdown compressor 5
ALC34 Alarm 7, compressor 5 Manual/automatic Settable Settable Shutdown compressor 5
ALC35 Alarm 7, compressor 5 Manual/automatic Settable Settable Shutdown compressor 5
ALC36 Alarm 1, compressor 6 Manual/automatic Settable Settable Shutdown compressor 6
ALC37 Alarm 2, compressor 6 Manual/automatic Settable Settable Shutdown compressor 6
ALC38 Alarm 3, compressor 6 Manual/automatic Settable Settable Shutdown compressor 6
ALC39 Alarm 4, compressor 6 Manual/automatic Settable Settable Shutdown compressor 6
ALC40 Alarm 5, compressor 6 Manual/automatic Settable Settable Shutdown compressor 6
ALC41 Alarm 6, compressor 6 Manual/automatic Settable Settable Shutdown compressor 6
ALC42 Alarm 7, compressor 6 Manual/automatic Settable Settable Shutdown compressor 6
ALC43 Alarm 1, compressor 7 Manual/automatic Settable Settable Shutdown compressor 7
ALC44 Alarm 2, compressor 7 Manual/automatic Settable Settable Shutdown compressor 7
ALC45 Alarm 1, compressor 8 Manual/automatic Settable Settable Shutdown compressor 8
ALC46 Alarm 2, compressor 8 Manual/automatic Settable Settable Shutdown compressor 8
ALC47 Alarm 1, compressor 9 Manual/automatic Settable Settable Shutdown compressor 9
ALC48 Alarm 2, compressor 9 Manual/automatic Settable Settable Shutdown compressor 9
ALC49 Alarm 1, compressor 10 Manual/automatic Settable Settable Shutdown compressor 10
ALC50 Alarm 1, compressor 11 Manual/automatic Settable Settable Shutdown compressor 11
ALC51 Alarm 1, compressor 12 Manual/automatic Settable Settable Shutdown compressor 12
ALC52 Alarm 1, compressor 1, line 2 Manual/automatic Settable Settable Shutdown compressor 1, line 2
ALC53 Alarm 2, compressor 1, line 2 Manual/automatic Settable Settable Shutdown compressor 1, line 2
ALC54 Alarm 3, compressor 1, line 2 Manual/automatic Settable Settable Shutdown compressor 1, line 2
ALC55 Alarm 4, compressor 1, line 2 Manual/automatic Settable Settable Shutdown compressor 1, line 2
ALC56 Alarm 5, compressor 1, line 2 Manual/automatic Settable Settable Shutdown compressor 1, line 2
ALC57 Alarm 6, compressor 1, line 2 Manual/automatic Settable Settable Shutdown compressor 1, line 2
ALC58 Alarm 7, compressor 1, line 2 Manual/automatic Settable Settable Shutdown compressor 1, line 2
ALC59 Alarm 1, compressor 2, line 2 Manual/automatic Settable Settable Shutdown compressor 2, line 2
ALC60 Alarm 2, compressor 2, line 2 Manual/automatic Settable Settable Shutdown compressor 2, line 2
ALC61 Alarm 3, compressor 2, line 2 Manual/automatic Settable Settable Shutdown compressor 2, line 2
ALC62 Alarm 4, compressor 2, line 2 Manual/automatic Settable Settable Shutdown compressor 2, line 2
ALC63 Alarm 5, compressor 2, line 2 Manual/automatic Settable Settable Shutdown compressor 2, line 2
ALC64 Alarm 6, compressor 2, line 2 Manual/automatic Settable Settable Shutdown compressor 2, line 2
ALC65 Alarm 7, compressor 2, line 2 Manual/automatic Settable Settable Shutdown compressor 2, line 2
ALC66 Alarm 1, compressor 3, line 2 Manual/automatic Settable Settable Shutdown compressor 3, line 2
ALC67 Alarm 2, compressor 3, line 2 Manual/automatic Settable Settable Shutdown compressor 3, line 2
ALC68 Alarm 3, compressor 3, line 2 Manual/automatic Settable Settable Shutdown compressor 3, line 2
ALC69 Alarm 4, compressor 3, line 2 Manual/automatic Settable Settable Shutdown compressor 3, line 2
ALC70 Alarm 5, compressor 3, line 2 Manual/automatic Settable Settable Shutdown compressor 3, line 2
ALC71 Alarm 6, compressor 3, line 2 Manual/automatic Settable Settable Shutdown compressor 3, line 2
ALC72 Alarm 7, compressor 3, line 2 Manual/automatic Settable Settable Shutdown compressor 3, line 2
ALC73 Alarm 1, compressor 4, line 2 Manual/automatic Settable Settable Shutdown compressor 4, line 2
ALC74 Alarm 2, compressor 4, line 2 Manual/automatic Settable Settable Shutdown compressor 4, line 2
ALC75 Alarm 3, compressor 4, line 2 Manual/automatic Settable Settable Shutdown compressor 4, line 2
ALC76 Alarm 4, compressor 4, line 2 Manual/automatic Settable Settable Shutdown compressor 4, line 2
ALC77 Alarm 5, compressor 4, line 2 Manual/automatic Settable Settable Shutdown compressor 4, line 2
ALC78 Alarm 6, compressor 4, line 2 Manual/automatic Settable Settable Shutdown compressor 4, line 2
ALC79 Alarm 7, compressor 4, line 2 Manual/automatic Settable Settable Shutdown compressor 4, line 2
ALC80 Alarm 1, compressor 5, line 2 Manual/automatic Settable Settable Shutdown compressor 5, line 2
ALC81 Alarm 2, compressor 5, line 2 Manual/automatic Settable Settable Shutdown compressor 5, line 2
ALC82 Alarm 3, compressor 5, line 2 Manual/automatic Settable Settable Shutdown compressor 5, line 2
ALC83 Alarm 4, compressor 5, line 2 Manual/automatic Settable Settable Shutdown compressor 5, line 2
ALC84 Alarm 5, compressor 5, line 2 Manual/automatic Settable Settable Shutdown compressor 5, line 2
ALC85 Alarm 6, compressor 5, line 2 Manual/automatic Settable Settable Shutdown compressor 5, line 2
ALC86 Alarm 7, compressor 5, line 2 Manual/automatic Settable Settable Shutdown compressor 5, line 2
ALC87 Alarm 1, compressor 6, line 2 Manual/automatic Settable Settable Shutdown compressor 6, line 2
ALC88 Alarm 2, compressor 6, line 2 Manual/automatic Settable Settable Shutdown compressor 6, line 2
ALC89 Alarm 3, compressor 6, line 2 Manual/automatic Settable Settable Shutdown compressor 6, line 2
ALC90 Alarm 4, compressor 6, line 2 Manual/automatic Settable Settable Shutdown compressor 6, line 2
ALC91 Alarm 5, compressor 6, line 2 Manual/automatic Settable Settable Shutdown compressor 6, line 2
ALC92 Alarm 6, compressor 6, line 2 Manual/automatic Settable Settable Shutdown compressor 6, line 2
ALC93 Alarm 7, compressor 6, line 2 Manual/automatic Settable Settable Shutdown compressor 6, line 2
ALC94 Alarm 1, compressor 7, line 2 Manual/automatic Settable Settable Shutdown compressor 7, line 2
ALC95 Alarm 2, compressor 7, line 2 Manual/automatic Settable Settable Shutdown compressor 7, line 2
ALC96 Alarm 1, compressor 8, line 2 Manual/automatic Settable Settable Shutdown compressor 8, line 2
ALC97 Alarm 2, compressor 8, line 2 Manual/automatic Settable Settable Shutdown compressor 8, line 2
ALC98 Alarm 1, compressor 9, line 2 Manual/automatic Settable Settable Shutdown compressor 9, line 2
ALC99 Alarm 2, compressor 9, line 2 Manual/automatic Settable Settable Shutdown compressor 9, line 2
ALCaa Alarm 1, compressor 10, line 2 Manual/automatic Settable Settable Shutdown compressor 10, line 2
ALCab Alarm 1, compressor 11, line 2 Manual/automatic Settable Settable Shutdown compressor 11, line 2
ALCac Alarm 1, compressor 12, line 2 Manual/automatic Settable Settable Shutdown compressor 12, line 2
ALCad High oil sump temperature, Digital Scroll™ Manual/automatic Settable R2 Shutdown compressor
ALCae High discharge temperature, Digital Scroll™ Manual/automatic Settable R2 Shutdown compressor
ALCaf High oil dilution, Digital Scroll™ Manual/automatic Settable R2 Shutdown compressor
ALCag High oil sump temperature, Digital Scroll™, line 2 Manual/automatic Settable R2 Shutdown compressor
ALCah High discharge temperature, Digital Scroll™, line 2 Manual/automatic Settable R2 Shutdown compressor
ALCai High oil dilution, Digital Scroll™, line 2 Manual/automatic Settable R2 Shutdown compressor
ALCal High discharge temperature compressors 1 to 6 Automatic 60s R2 Related functions disabled
ALCam High discharge temperature compressors 1 to 6, line 2 Automatic 60s R2 Related functions disabled
AlCan Compressor envelope Manual Settable R1 Shutdown compressor
ALCao High compressor oil temperature, line 1 Automatic Settable R2 -
AlCap High compressor oil temperature, line 2 Automatic Settable R2 -
ALF01 Fan circuit breaker Manual/automatic Settable R2 Shutdown fans
ALF02 Fan circuit breaker, line 2 Manual/automatic Settable R2 Shutdown fans
ALG01 Clock error Automatic - R2 Related functions disabled
ALG02 Extended memory error Automatic - R2 Related functions disabled
ALG11 Generic high temperature alarms 1 to 5, PLB1 Manual/automatic Settable Settable -
ALG12 Generic high temperature alarms 1 to 5, PLB2 Manual/automatic Settable Settable -
ALG13 Generic high temperature alarms 1 to 5, PLB3 Manual/automatic Settable Settable -
ALG14 Generic high temperature alarms 1 to 5, PLB4 Manual/automatic Settable Settable -
