pRack +0300025EN rel. 1.3 - 17.12.2015

Code Description Reset Delay Alarm relay Action

ALG15 Generic low temperature alarms 1 to 5, PLB1 Manual/automatic Settable Settable -

ALG16 Generic low temperature alarms 1 to 5, PLB2 Manual/automatic Settable Settable -

ALG17 Generic low temperature alarms 1 to 5, PLB3 Manual/automatic Settable Settable -

ALG18 Generic low temperature alarms 1 to 5, PLB4 Manual/automatic Settable Settable -

ALG19 Generic high modulation alarms 6 and 7, PLB1 Manual/automatic Settable Settable -

ALG20 Generic high modulation alarms 6 and 7, PLB2 Manual/automatic Settable Settable -

ALG21 Generic high modulation alarms 6 and 7, PLB3 Manual/automatic Settable Settable -

ALG22 Generic high modulation alarms 6 and 7, PLB4 Manual/automatic Settable Settable -

ALG23 Generic low modulation alarms 6 and 7, PLB1 Manual/automatic Settable Settable -

ALG24 Generic low modulation alarms 6 and 7, PLB2 Manual/automatic Settable Settable -

ALG25 Generic low modulation alarms 6 and 7, PLB3 Manual/automatic Settable Settable -

ALG26 Generic low modulation alarms 6 and 7, PLB4 Manual/automatic Settable Settable -

ALG27 Normal alarm generic functions 8/9, PLB1 Manual/automatic Settable Settable -

ALG28 Serious alarm generic functions 8/9, PLB1 Manual/automatic Settable Settable -

ALG29 Normal alarm generic functions 8/9, PLB2 Manual/automatic Settable Settable -

ALG30 Serious alarm generic functions 8/9, PLB2 Manual/automatic Settable Settable -

ALG31 Normal alarm generic functions 8/9, PLB3 Manual/automatic Settable Settable -

ALG32 Serious alarm generic functions 8/9, PLB3 Manual/automatic Settable Settable -

ALG33 Normal alarm generic functions 8/9, PLB4 Manual/automatic Settable Settable -

ALG34 Serious alarm generic functions 8/9, PLB4 Manual/automatic Settable Settable -

ALH01 ChillBooster fault Automatic Settable R2 Disable ChillBooster

ALH02 ChillBooster fault, line 2 Automatic Settable R2 Disable ChillBooster

ALO02 pLAN malfunction Automatic 60s R1 Shutdown unit

ALT01 Compressor maintenance request Manual - Not featured -

ALT02 Compressor maintenance request, line 2 Manual - Not featured -

ALT03 ChillBooster maintenance request manual 0s Not featured -

ALT04 ChillBooster maintenance request, line 2 manual 0s Not featured -

ALU01 Conﬁ guration not allowed Automatic Not featured Not featured Shutdown unit

ALU02 Control probes missing Automatic Not featured Not featured Shutdown unit

ALW01 High pressure prevent warning Automatic Settable Not featured Shutdown compressor, except mini-

mum load stage

ALW02 High pressure prevent warning, line 2 Automatic Settable Not featured Shutdown compressor line 2, except

minimum load stage

ALW03 Compressor inverter warning Automatic Not featured Not featured -

ALW04 Compressor inverter warning, line 2 Automatic Not featured Not featured -

ALW05 Fan inverter warning Automatic Not featured Not featured -

ALW06 Fan inverter warning, line 2 Automatic Not featured Not featured -

ALW07 Envelope warning: refrigerant not compatible with compressor series Automatic Not featured Not featured -

ALW08 Envelope warning: custom envelope not conﬁ gured Automatic Not featured Not featured -

ALW09 Envelope warning: suction or condensing probes not conﬁ gured Automatic Not featured Not featured -

ALW10 Low superheat warning Automatic Not featured Not featured -

ALW11 Low superheat warning, line 2 Automatic Not featured Not featured -

ALW12 Warning, ChillBooster operating without outside sensor Automatic 0s Not featured -

ALW13 Warning, ChillBooster operating without outside sensor, line 2 Automatic 0s Not featured -

ALE01 EEV motor error on Driver 1 Automatic Conﬁ g. Conﬁ g. -

ALE01 High condensing temperature on Driver 1 Automatic Conﬁ g. Conﬁ g. -

ALE01 Low suction temperature on Driver 1 Automatic Conﬁ g. Conﬁ g. -

ALE02 Low superheat on Driver 1 Automatic Conﬁ g. Conﬁ g. -

ALE02 Low operating pressure on Driver 1 Automatic Conﬁ g. Conﬁ g. -

ALE02 Maximum operating pressure on Driver 2 Automatic Conﬁ g. Conﬁ g. -

ALE03 EEV motor error on Driver 2 Automatic Conﬁ g. Conﬁ g. -

ALE03 High condensing temperature on Driver 2 Automatic Conﬁ g. Conﬁ g. -

ALE03 Low suction temperature on Driver 2 Automatic Conﬁ g. Conﬁ g. -

ALE04 Low superheat on Driver 2 Automatic Conﬁ g. Conﬁ g. -

ALE04 Low operating pressure on Driver 2 Automatic Conﬁ g. Conﬁ g. -

ALE04 Maximum operating pressure on Driver 2 Automatic Conﬁ g. Conﬁ g. -

ALE05 EEPROM error on Driver 1 in PLB1 Automatic Conﬁ g. Conﬁ g. -

ALE05 Probe S1 error on Driver 1 in PLB1 Automatic Conﬁ g. Conﬁ g. -

ALE05 Probe S2 error on Driver 1 in PLB1 Automatic Conﬁ g. Conﬁ g. -

ALE05 Probe S3 error on Driver 1 in PLB1 Automatic Conﬁ g. Conﬁ g. -

ALE05 Probe S4 error on Driver 1 in PLB1 Automatic Conﬁ g. Conﬁ g. -

ALE05 Oﬄ ine error on Driver 1 in PLB1 Automatic Conﬁ g. Conﬁ g. -

ALE05 Battery error on Driver 1 in PLB1 Automatic Conﬁ g. Conﬁ g. -

ALE07 EEPROM error on Driver 1 in PLB3 Automatic Conﬁ g. Conﬁ g. -

ALE07 Probe S1 error on Driver 1 in PLB3 Automatic Conﬁ g. Conﬁ g. -

ALE07 Probe S2 error on Driver 1 in PLB3 Automatic Conﬁ g. Conﬁ g. -

ALE07 Probe S3 error on Driver 1 in PLB3 Automatic Conﬁ g. Conﬁ g. -

ALE07 Probe S4 error on Driver 1 in PLB3 Automatic Conﬁ g. Conﬁ g. -

ALE07 Oﬄ ine error on Driver 1 in PLB3 Automatic Conﬁ g. Conﬁ g. -

ALE07 Battery error on Driver 1 in PLB3 Automatic Conﬁ g. Conﬁ g. -

ALE08 EEPROM error on Driver 2 in PLB1 Automatic Conﬁ g. Conﬁ g. -

ALE08 Probe S1 error on Driver 2 in PLB1 Automatic Conﬁ g. Conﬁ g. -

ALE08 Probe S2 error on Driver 2 in PLB1 Automatic Conﬁ g. Conﬁ g. -

ALE08 Probe S3 error on Driver 2 in PLB1 Automatic Conﬁ g. Conﬁ g. -

ALE08 Probe S4 error on Driver 2 in PLB1 Automatic Conﬁ g. Conﬁ g. -

ALE08 Oﬄ ine error on Driver 2 in PLB1 Automatic Conﬁ g. Conﬁ g. -

ALE08 Battery error on Driver 2 in PLB1 Automatic Conﬁ g. Conﬁ g. -

ALE10 EEPROM error on Driver 2 in PLB3 Automatic Conﬁ g. Conﬁ g. -

ALE10 Probe S1 error on Driver 2 in PLB3 Automatic Conﬁ g. Conﬁ g. -

ALE10 Probe S2 error on Driver 2 in PLB3 Automatic Conﬁ g. Conﬁ g. -

ALE10 Probe S3 error on Driver 2 in PLB3 Automatic Conﬁ g. Conﬁ g. -

ALE10 Probe S4 error on Driver 2 in PLB3 Automatic Conﬁ g. Conﬁ g. -

ALE10 Oﬄ ine error on Driver 2 in PLB3 Automatic Conﬁ g. Conﬁ g. -

ALE10 Battery error on Driver 2 in PLB3 Automatic Conﬁ g. Conﬁ g. -

ALE11 Parameter transmission error on Driver 1 Automatic 0 Conﬁ g. -

ALE12 Parameter transmission error on Driver 2 Automatic 0 Conﬁ g. -

ALE13 FW compatibility error on Driver 1 Automatic 0 Conﬁ g. -

ALE14 FW compatibility error on Driver 2 Automatic 0 Conﬁ g. -

Tab. A.e
