pRack +0300025EN rel. 1.3 - 17.12.2015
Mask Index Description Chan. Logic Notes
Line 2
Suction
Ac08, Baacy Unit ON/OFF line 2
Baaap, Cbaah Common low pressure switch line 2
Baadb, Cba14 Compressor inverter warning line 2
Baaar, Cbaaj Common oil alarm line 2
Baa61, Cba01 Alarm 1 compressor 1 line 2
Baa62, Cba02 Alarm 2 compressor 1 line 2
Baa63, Cba03 Alarm 3 compressor 1 line 2
Baa64, Cba04 Alarm 4 compressor 1 line 2
Baa65, Cba05 Alarm 5 compressor 1 line 2
Baa66, Cba06 Alarm 6 compressor 1 line 2
Baa67, Cba07 Alarm 7 compressor 1 line 2
Baa68, Cba15 Alarm 1 compressor 2 line 2
Baa69, Cba16 Alarm 2 compressor 2 line 2
Baa70, Cba17 Alarm 3 compressor 2 line 2
Baa71, Cba18 Alarm 4 compressor 2 line 2
Baa72, Cba19 Alarm 5 compressor 2 line 2
Baa73, Cba20 Alarm 6 compressor 2 line 2
Baa74, Cba21 Alarm 7 compressor 2 line 2
Baa76, Cba28 Alarm 1 compressor 3 line 2
Baa77, Cba29 Alarm 2 compressor 3 line 2
Baa78, Cba30 Alarm 3 compressor 3 line 2
Baa79, Cba31 Alarm 4 compressor 3 line 2
Baa80, Cba32 Alarm 5 compressor 3 line 2
Baa81, Cba33 Alarm 6 compressor 3 line 2
Baa82, Cba34 Alarm 7 compressor 3 line 2
Baa83, Cba40 Alarm 1 compressor 4 line 2
Baa84, Cba41 Alarm 2 compressor 4 line 2
Baa85, Cba42 Alarm 3 compressor 4 line 2
Baa86, Cba43 Alarm 4 compressor 4 line 2
Baa87, Cba44 Alarm 5 compressor 4 line 2
Baa88, Cba45 Alarm 6 compressor 4 line 2
Baa89, Cba46 Alarm 7 compressor 4 line 2
Baa91, Cba53 Alarm 1 compressor 3 line 2
Baa92, Cba54 Alarm 2 compressor 3 line 2
Baa93, Cba55 Alarm 3 compressor 3 line 2
Baa94, Cba56 Alarm 4 compressor 3 line 2
Baa95, Cba57 Alarm 5 compressor 3 line 2
Baa96, Cba58 Alarm 6 compressor 3 line 2
Baa97, Cba59 Alarm 7 compressor 3 line 2
Baa98, Cba65 Alarm 1 compressor 4 line 2
Baa99, cba66 Alarm 2 compressor 4 line 2
Baaaa, Cba67 Alarm 3 compressor 4 line 2
Baaab, Cba68 Alarm 4 compressor 4 line 2
Baaac, Cba69 Alarm 5 compressor 4 line 2
Baaad, Cba70 Alarm 6 compressor 4 line 2
Baaae, Cba71 Alarm 7 compressor 4 line 2
Baaag, Cba78 Alarm 1 compressor 7 line 2
Baaah, Cba79 Alarm 2 compressor 7 line 2
Baaai, Cba84 Alarm 1 compressor 8 line 2
Baaaj, Cba85 Alarm 2 compressor 8 line 2
Baaak, Cba90 Alarm 1 compressor 9 line 2
Baaal, Cba91 Alarm 2 compressor 9 line 2
Baaam, Cba95 Alarm 1 compressor 10 line 2
Baaan, Cba99 Alarm 1 compressor 11 line 2
Baaao, Cbaad Alarm 1 compressor 12 line 2
Baaas, Cbaak Liquid level alarm line 2
Condenser
Baadd Fan inverter warning line 2
Baaaq Common high pressure switch line 2
Baabn, Dba01 Fan overload 1 line 2
Baabo, Dba02 Fan overload 2 line 2
Baabp, Dba03 Fan overload 3 line 2
Baabq, Dba04 Fan overload 4 line 2
Baabr, Dba05 Fan overload 5 line 2
Baabs, Dba06 Fan overload 6 line 2
Baabt, Dba07 Fan overload 7 line 2
Baabu, Dba08 Fan overload 8 line 2
Baabv, Dba09 Fan overload 9 line 2
Baabw, Dba10 Fan overload 10 line 2
Baabx, Dba11 Fan overload 11 line 2
Baaby, Dba12 Fan overload 12 line 2
Baabz, Dba13 Fan overload 13 line 2
Baaca, Dba14 Fan overload 14 line 2
Baacb, Dba15 Fan overload 15 line 2
Baacc, Dba16 Fan overload 16 line 2
Baacd, Dba17 Common fan overload line 2
Other functions
Baace Heat recovery line 2
Egba01 ChillBooster fault line 2
Baade Enable fl oating condensing line 2
Baacm, Cbd06, Dbd08 Set point compensation line 2
Dba43 Anti noise line 2
Dba44 Split condenser line 2
Dba45 Enable fl oating condensing line 2
Eeba02 Heat recovery activation line 2
Comuni
Baacf, Efe16 Generic DI F
Baacg, Efe17 Generic DI G
Baach, Efe18 Generic DI H
Baaci, Efe19 Generic DI I
Baacj, Efe20 Generic DI J
Baacn pRack automatic or manual operation
Baadf pLoads digital input 1
Baadg pLoads digital input 2
Tab. A.f
