Digital outputs
Mask Index Description Chan. Logic Notes
Line 1
Suction
Bac02, Caa08 Line relay compressor 1 line 1
Partwinding/Star relay compressor 1 line 1
Delta relay compressor 1 line 1
Bac03, Caa09 Valve 1 compressor 1 line 1
Bac04, Caa10 Valve 2 compressor 1 line 1
Bac05, Caa11 Valve 3 compressor 1 line 1
Bac07, Caa12 Balancing valve compressor 1 line 1
Bac08, Caa22 Line relay compressor 2 line 1
Partwinding/Star relay compressor 2 line 1
Delta relay compressor 2 line 1
Bac10, Caa23 Valve 1 compressor 2 line 1
Bac11, Caa24 Valve 2 compressor 1 line 1
Bac12, Caa25 Valve 3 compressor 1 line 1
Bac13, Caa26 Balancing valve compressor 1 line 1
Bac15, Caa35 Line relay compressor 3 line 1
Partwinding/Star relay compressor 3 line 1
Delta relay compressor 3 line 1
Bac16, Caa36 Valve 1 compressor 3 line 1
Bac17, Caa37 Valve 2 compressor 3 line 1
Bac18, Caa38 Valve 3 compressor 3 line 1
Bac20, Caa39 Balancing valve compressor 3 line 1
Bac21, Caa47 Line relay compressor 4 line 1
Partwinding/Star relay compressor 4 line 1
Delta relay compressor 4 line 1
Bac22, Caa48 Valve 1 compressor 4 line 1
Bac23, Caa49 Valve 2 compressor 4 line 1
Bac24, Caa50 Valve 3 compressor 4 line 1
Bac26, Caa51 Balancing valve compressor 4 line 1
Bac28, Caa60 Line relay compressor 5 line 1
Partwinding/Star relay compressor 5 line 1
Delta relay compressor 5 line 1
Bac29, Caa61 Valve 1 compressor 5 line 1
Bac30, Caa62 Valve 2 compressor 5 line 1
Bac31, Caa63 Valve 3 compressor 5 line 1
Bac33, Caa64 Balancing valve compressor 5 line 1
Bac34, Caa72 Line relay, compressor 6 line 1
Partwinding/Star relay, compressor 6 line 1
Delta relay, compressor 6 line 1
Bac35, Caa73 Valve 1, compressor 6 line 1
Bac36, Caa74 Valve 2, compressor 6 line 1
Bac37, Caa75 Valve 3, compressor 6 line 1
Bac39, Caa76 Balancing valve, compressor 6 line 1
Bac41, Caa80 Line relay compressor 7 line 1
Partwinding/Star relay compressor 7 line 1
Delta relay compressor 7 line 1
Bac42, Caa81 Valve 1 compressor 7 line 1
Bac43, Caa82 Valve 2 compressor 7 line 1
Bac45, Caa83 Balancing valve compressor 7 line 1
Bac46, Caa86 Line relay compressor 8 line 1
Partwinding/Star relay compressor 8 line 1
Delta relay compressor 8 line 1
Bac47, Caa87 Valve 1 compressor 8 line 1
Bac48, Caa88 Valve 2 compressor 8 line 1
Bac50, Caa89 Balancing valve compressor 8 line 1
Bac51, Caa92 Line relay compressor 9 line 1
Partwinding/Star relay compressor 9 line 1
Delta relay compressor 9 line 1
Bac52, Caa93 Valve 1 compressor 9 line 1
Bac55, Caa94 Balancing valve compressor 9 line 1
Bac56, Caa96 Line relay compressor 10 line 1
Partwinding/Star relay compressor 10 line 1
Delta relay compressor 10 line 1
Bac57, Caa97 Valve 1 compressor 10 line 1
Bac60, Caa98 Balancing valve compressor 10 line 1
Bac61, Caaaa Relay line compressor 11 line 1
Partwinding/Star relay compressor 11 line 1
Delta relay compressor 11 line 1
Bac62, Caaab Valve 1 compressor 11 line 1
Bac65, Caaac Balancing valve compressor 11 line 1
Bac66, Caaae Relay line compressor 12 line 1
Partwinding/Star relay compressor 12 line 1
Delta relay compressor 12 line 1
Bac67, Caaaf Valve 1 compressor 12 line 1
Bac70, Caaag Balancing valve compressor 12 line 1
Ebaa01 Subcooling valve line 1
Line 1
Condenser
Bacbt, Daa21 Fan 1 line 1
Bacbu, Daa22 Fan 2 line 1
Bacbv, Daa23 Fan 3 line 1
Bacbw, Daa24 Fan 4 line 1
Bacbx, Daa25 Fan 5 line 1
Bacby, Daa26 Fan 6 line 1
Bacbz, Daa27 Fan 7 line 1
Bacca, Daa28 Fan 8 line 1
Baccb, Daa29 Fan 9 line 1
Baccc, Daa30 Fan 10 line 1
Baccd, Daa31 Fan 11 line 1
Bacce, Daa32 Fan 12 line 1
Baccf, Daa33 Fan 13 line 1
Baccg, Daa34 Fan 14 line 1
Bacch, Daa35 Fan 15 line 1
Bacci, Daa36 Fan 16 line 1
