pRack +0300025EN rel. 1.3 - 17.12.2015
Mask Index Description Chan. Logic Notes
Line 1
Other functions
Bacck, Eeaa03 Heat recovery pump line 1
Baccl, Egaa02 ChillBooster line 1
Bacdp, Eaaa11 Oil pump 1 line 1
Bacdq, Eaaa12 Oil pump 2 line 1
Bacdr, Eaaa13 Oil fan line 1
Bacdv, Ecaa07, Edaa07 Liquid injection valve/Economizer compressor 1 line 1
Bacdw, Ecaa08, Edaa08 Liquid injection valve/Economizer compressor 2 line 1
Bacdx, Ecaa09, Edaa09 Liquid injection valve/Economizer compressor 3 line 1
Bacdy, Ecaa10, Edaa10 Liquid injection valve/Economizer compressor 4 line 1
Bacdz, Ecaa11, Edaa11 Liquid injection valve/Economizer compressor 5 line 1
Bacea, Ecaa12, Edaa12 Liquid injection valve/ Economizer, compressor 6 line 1
Bac01 Anti liquid return line 1
Bacei Force from BMS line 1
Bacek, Ebaa01 Subcooling line 1
Eaaa15 Oil cooling pump screw compressor 1 line 1
Eaaa16 Oil cooling fan screw compressor 1 line 1
Eaaa18 Oil cooling pump screw compressor 2 line 1
Eaaa19 Oil cooling fan screw compressor 2 line 1
Eaaa40 Oil level valve compressor 1 line 1
Eaaa41 Oil level valve compressor 2 line 1
Eaaa42 Oil level valve compressor 3 line 1
Eaaa43 Oil level valve compressor 4 line 1
Eaaa44 Oil level valve compressor 5 line 1
Eaaa45 Oil level valve, compressor 6 line 1
Line 2
Suction
Bac73, Cba08 Relay line compressor 1 line 2
Partwinding/Star relay compressor 1 line 2
Delta relay compressor 1 line 2
Bac74, Cba09 Valve 1 compressor 1 line 2
Bac75, Cba10 Valve 2 compressor 1 line 2
Bac76, Cba11 Valve 3 compressor 1 line 2
Bac78, Cba12 Balancing valve compressor 1 line 2
Bac79, Cba22 Line relay compressor 2 line 2
Partwinding/Star relay compressor 2 line 2
Delta relay compressor 2 line 2
Bac80, Cba23 Valve 1 compressor 2 line 2
Bac81, Cba24 Valve 2 compressor 1 line 2
Bac82, Cba25 Valve 3 compressor 1 line 2
Bac84, Cba26 Balancing valve compressor 1 line 2
Bac86, Cba35 Line relay compressor 3 line 2
Partwinding/Star relay compressor 3 line 2
Delta relay compressor 3 line 2
Bac87, Cba36 Valve 1 compressor 3 line 2
Bac88, Cba37 Valve 2 compressor 3 line 2
Bac89, Cba38 Valve 3 compressor 3 line 2
Bac91, Cba39 Balancing valve compressor 3 line 2
Bac92, Cba47 Line relay compressor 4 line 2
Partwinding/Star relay compressor 4 line 2
Delta relay compressor 4 line 2
Bac94, Cba48 Valve 1 compressor 4 line 2
Bac95, Cba49 Valve 2 compressor 4 line 2
Bac96, Cba50 Valve 3 compressor 4 line 2
Bac98, Cba51 Balancing valve compressor 4 line 2
Bacaa, Cba60 Line relay compressor 5 line 2
Partwinding/Star relay compressor 5 line 2
Delta relay compressor 5 line 2
Bacab, Cba61 Valve 1 compressor 5 line 2
Bacac, Cba62 Valve 2 compressor 5 line 2
Bacad, Cba63 Valve 3 compressor 5 line 2
Bacaf, Cba64 Balancing valve compressor 5 line 2
Ebba01 Subcooling valve line 2
