Carel PRK300S3F0

101
ENG
pRack +0300025EN rel. 1.3 - 17.12.2015
Mask Index Description Chan. Logic Notes
Line 2
Suction
Bacag, Cba72 Line relay, compressor 6 line 2
Partwinding/Star relay, compressor 6 line 2
Delta relay, compressor 6 line 2
Bacah, Cba73 Valve 1 compressor 6 line 2
Bacai, Cba74 Valve 2 compressor 6 line 2
Bacaj, Cba75 Valve 3 compressor 6 line 2
Bacal, Cba76 Balancing valve, compressor 6 line 2
Bacan, Cba80 Line relay compressor 7 line 2
Partwinding/Star relay compressor 7 line 2
Delta relay compressor 7 line 2
Bacao, Cba81 Valve 1 compressor 7 line 2
Bacap, Cba82 Valve 2 compressor 7 line 2
Bacar, Cba83 Balancing valve compressor 7 line 2
Bacas Cba86 Line relay compressor 8 line 2
Partwinding/Star relay compressor 8 line 2
Delta relay compressor 8 line 2
Bacat, Cba87 Valve 1 compressor 8 line 2
Bacau, Cba88 Valve 2 compressor 8 line 2
Bacaw, Cba89 Balancing valve compressor 8 line 2
Bacax, Cba92 Line relay compressor 9 line 2
Partwinding/Star relay compressor 9 line 2
Delta relay compressor 9 line 2
Bacay, Cba93 Valve 1 compressor 9 line 2
Bacbb, Cba94 Balancing valve compressor 9 line 2
Bacbc, Cba96 Line relay compressor 10 line 2
Partwinding/Star relay compressor 10 line 2
Delta relay compressor 10 line 2
Bacbd, Cba97 Valve 1 compressor 10 line 2
Bacbg, Cba98 Balancing valve compressor 10 line 2
Bacbh, Cbaaa Line relay compressor 11 line 2
Partwinding/Star relay compressor 11 line 2
Delta relay compressor 11 line 2
Bacbi, Cbaab Valve 1 compressor 11 line 2
Bacbl, Cbaac Balancing valve compressor 11 line 2
Bacbm, Cbaae Line relay compressor 12 line 2
Partwinding/Star relay compressor 12 line 2
Delta relay compressor 12 line 2
Bacbn, Cbaaf Valve 1 compressor 12 line 2
Bacbq, Cbaag Balancing valve compressor 12 line 2
Line 2
Condenser
Baccn, Dba20 Fan1 line 2
Bacco, Dba21 Fan 2 line 2
Baccp, Dba22 Fan 3 line 2
Baccq, Dba23 Fan 4 line 2
Baccr, Dba24 Fan 5 line 2
Baccs, Dba25 Fan 6 line 2
Bacct, Dba26 Fan 7 line 2
Baccu, Dba27 Fan 8 line 2
Baccv, Dba28 Fan 9 line 2
Baccw, Dba29 Fan 10 line 2
Baccx, Dba30 Fan 11 line 2
Baccy, Dba31 Fan 12 line 2
Baccz, Dba32 Fan 13 line 2
Bacda, Dba33 Fan 14 line 2
Bacdb, Dba34 Fan 15 line 2
Bacdc, Dba35 Fan 16 line 2
Bacdd, Dba36 Fan inverter line 2
Other functions
Bacde, Eeba03 Heat recovery pump line 2
Bacdf, Egba02 ChillBooster line 2
Bacds, Eaba10 Oil pump 1 line 2
Bacdt, Eaba11 Oil pump 2 line 2
Bacdu, Eaba12 Oil fan line 2
Baceb, Ecba07, Edba07 Liquid injection valve compressor 1 line 2
Bacec, Ebca08, Edba08 Liquid injection valve compressor 2 line 2
Baced, Ecba09, Edba09 Liquid injection valve compressor 3 line 2
Bacee, Ecba10, Edba10 Liquid injection valve compressor 4 line 2
Bacef, Ecba11, Edba11 Liquid injection valve compressor 5 line 2
Baceg, Ecba12, Edba12 Liquid injection valve compressor 6 line 2
Bac72 Anti liquid return line 2
Bacej Force from BMS line 2
Bacel, Ebbb01 Subcooling line 2
Eaba40 Oil level valve compressor 1 line 2
Eaba41 Oil level valve compressor 2 line 2
Eaba42 Oil level valve compressor 3 line 2
Eaba43 Oil level valve compressor 4 line 2
Eaba44 Oil level valve compressor 5 line 2
Eaba45 Oil level valve, compressor 6 line 2
Common
Bacdg, Efe21 Generic stage function 1
Bacdh, Efe22 Generic stage function 2
Bacdi, Efe23 Generic stage function 3
Bacdj, Efe24 Generic stage function 4
Bacdk, Efe25 Generic stage function 5
Bacdl Active alarms
Bacdm, Efe26 Generic alarm function 1
Bacdn, Efe27 Generic alarm function 2
Bacdo, Efe28 Generic scheduling function
Baceh Sign of life
Bacem Minor alarm
Bacen Serious alarm
Tab. A.g
