Analogue inputs
Mask Index Description Chan. Logic Notes
Suct.
Bab01, Caaal Return pressure probe line 1
Bab02, Caaam Return backup pressure probe line 1
Bab03, Caaao Return temperature probe line 1
C.
Bab04, Daa39 Condensing pressure probe line 1
Bab09, Daa40 Backup condensing pressure probe line 1
Other functions
Bab11, Daa41 Discharge temperature probe line 1
Bab12 Liquid temperature probe line 1
Bab13, Eeaa05 Heat recovery outlet temperature probe line 1
Bab15, Daa20 Outside temperature probe line 1
Bab16 Room temperature probe line 1
Bab17, Eaaa04 Oil temperature probe line 1
Bab29, Ecaa01, Edaa01 Discharge temperature probe compressor 1 line 1
Bab30, Ecaa02 Edaa02 Discharge temperature probe compressor 2 line 1
Bab31, Ecaa03, Edaa03 Discharge temperature probe compressor 3 line 1
Bab32, Ecaa04, Edaa04 Discharge temperature probe compressor 4 line 1
Bab33, Ecaa05, Edaa05 Discharge temperature probe compressor 5 line 1
Bab34, Ecaa06, Edaa06 Discharge temperature probe, compressor 6 line 1
Bab41, Eaaa05 Oil temperature probe compressor 1 line 1
Bab42, Eaaa06 Oil temperature probe compressor 2 line 1
Bab43, Eaaa07 Oil temperature probe compressor 3 line 1
Bab44, Eaaa08 Oil temperature probe compressor 4 line 1
Bab45, Eaaa09 Oil temperature probe compressor 5 line 1
Bab46, Eaaa10 Oil temperature probe compressor 6 line 1
Line 2
Suct.
Bab05, Caal Return pressure probe line 2
Bab06, Caaam Return backup pressure probe line 2
Bab07, Caaao Return temperature probe line 2
C.
Bab08, Dba39 Condensing pressure probe line 2
Bab10, Dba40 Backup condensing pressure probe line 2
Other
Bab48, Dba38 Discharge temperature probe line 2
Bab49 Liquid temperature probe line 2
Bab14, Eeba05 Heat recovery outlet temperature probe line 2
Bab18, Eaba04 Oil temperature probe line 2
Bab35, Ecba01, Edba01 Discharge temperature probe compressor 1 line 2
Bab36, Ecba02, Edba02 Discharge temperature probe compressor 2 line 2
Bab37, Ecba03, Edba03 Discharge temperature probe compressor 3 line 2
Bab38, Ecba04, Edba04 Discharge temperature probe compressor 4 line 2
Bab39, Ecba05, Edba05 Discharge temperature probe compressor 5 line 2
Bab40, Ecba06, Edba06 Discharge temperature probe, compressor 6 line 2
Bab47, Eaba05 Oil temperature probe compressor 1 line 2
Common
Bab19, Efe06 Generic active probe A
Bab20, Efe07 Generic passive probe A
Bab21, Efe08 Generic active probe B
Bab22, Efe09 Generic passive probe B
Bab23, Efe10 Generic active probe C
Bab24, Efe11 Generic passive probe C
Bab25, Efe12 Generic active probe D
Bab26, Efe13 Generic passive probe D
Bab27, Efe14 Generic active probe E
Bab28, Efe15 Generic passive probe E
Bab58 Energy meter
Tab. A.h
Analogue outputs
Mask Index Description Chan. Logic Notes
Line 1
Bad01, Caa14 Compressor inverter output line 1
Bad02, Eaaa14 Oil pump output line 1
Bad07, Daa38 Fan inverter output line 1
Bad08, Eeaa04 Heat recovery valve output line 1
Bad12, Efe29 Generic modulating output 1
Eaaa17 Oil cooling pump output screw compressor 1
Line 2
Bad04 Compressor inverter output line 2
Bad05, Eaba13 Oil pump output line 2
Bad10, Dba37 Fan inverter output line 2
Bad11, Eeba04 Heat recovery valve output line 2
Bad13, Efe30 Generic modulating output 2
Eaaa20 Oil cooling pump output screw compressor 2
Tab. A.i
