Carlton SP4012 - Control Valve Assembly

SP4012 HYDRAULIC ASSEMBLY
71
CONTROL VALVE ASSEMBLY
ITEM NO PART NO DESCRIPTION QTY
1 0300199F Work Section - SVS1GA1AA 4
2 0300199G Valve Section - SVH1BA1AA 1
3 0300199H Prince Inlet Section - SVI 1
4 0300199I Outlet Section – SVE 1
5 0300064 Relief Valve 1
6 0300261 Steel Plug, 1/2 SAE 2
7 0300072 O-Ring 1
8 0300069 Back-Up Washer 1
9 0300073 O-Ring 1
10 0300074 O-Ring 1
11 0300075 O-Ring 14
12 0300065 Relief Plug 10
13 0300199L Valve Spool End Cap 5
14 0300060 Handle Flange 5
15 0300199M Prince Handle Linkage 5
16 0300199N Prince Valve Spool Extension 5
17 0300063 Valve Handle Kit 5
18 0300076 O-Ring 4
19 0300070 Spool Back-Up Washer 10
20 0300077 O-Ring 10
21 0300078 O-Ring 16
22 0300066 Load Check Poppet 5
23 0300067 Spring 5
24 0300068 Load Check Plug 5
25 0300071 Back-Up Washer 10
26 0300079 O-Ring 10
NOTES:
1. SVS work section seal kit - P/N 0300199ZA - Includes items 11,18,20,21,25.
2. SVH work section seal kit - P/N 0300199ZB - Includes items 10,11,20,21,25.
3. SVI inlet section seal kit - P/N 0300199ZC - Includes items 10,11.
