Carlton SP4012 - Front Axle Assembly

SP4012 FRONT AXLE ASSEMBLY
77
ITEM NO PART NO DESCRIPTION QTY
1 05500091 Tire Assembly 25-4 5 Lug 2
2 0550102 Lug Nut - 1/2-20 10
3 2300289 R/H Steering Frame 1
4 2300290 L/H Steering Frame 1
5 0550208 E/Z Lube Grease Seal 2
6 0550209 Inner Bearing - 3500# 2
7 0550210 Inner Bearing Race - 3500# 2
8 0550009H Hub w/Cups & Studs 2
9 0550213 Outer Bearing Race – 3500# 6
10 0550214 Outer Bearing – 3500# 6
11 0550215 Spindle Washer 4
12 0550216 Spindle Jam Nut - 1”-14 4
13 0550217 Tang Washer 4
14 0550218 Grease Cap for E/Z Lube – 3500# 2
15 0550219 Rubber Plug for EZ Lube Cap 2
16 3504133 Steering Linkage 1
17 2300280 Weld-on Seal Ring 2
18 12G-1010 Shoulder Bolt, 5/8” x 1 1/4" (1/2-13) 2
19 0150305 5/8 Flat Washer 2
20 0300105 Hydraulic Cylinder - 2x4 1
21 0150801 Hardened Spring Bushing - 1” 2
22 0300105N Prince Cyl. Pin - Short 2
23 1/4-28 x 2” HHCS 4
24 2300158 Ground Stake Rod - 2500 1
25 0150604 Lock Pin - 3/8 x 2 3/4 1
26 0150805 Hardened Spring Bushing - 5/8" 2
27 1/2" Flat Washer 2
28 0550104 Grease Seal – 10-9 2
29 0550109 End Cap – 3500# 2
30 0150206 1/2-13 Lock Nut 2
