SP4012 HYDRAULIC ASSEMBLY
73
OPTIONAL:
STEERING HYDRAULIC ASSEMBLY
(ALL WHEEL DRIVE)
ITEM NO PART NO DESCRIPTION QTY
1 0300199 Work Section 1
2 0300105W Hydraulic Cylinder – 2 x 6 1
3 0300257 3/8 JIC- 1/2 ORB - 6400-6-8 2
4
1/2" O-Ring - 3/8” JIC 90°
2
5 H250426 Hose Assembly
1
6 H250425 Hose Assembly
2
