SP4012 FRONT AXLE ASSEMBLY
79
OPTIONAL:
ALL WHEEL DRIVE
ITEM NO PART NO DESCRIPTION QTY
1 05500091 Tire Assembly 25-4 5 Lug 2
2 0550102 Lug Nut – 1/2-20 10
3 14060030 Weldment, Mount, AWD Motor, RH 1
4 14060031 Weldment, Mount, AWD Motor, LH 1
5 0550208 E/Z Lube Grease Seal 2
6 0550209 Inner Bearing - 3500# 2
7 0550210 Inner Bearing Race - 3500# 2
8 0550009H Rear Tapered Hub 25-4 2
9 0550213 Outer Bearing Race - 3500# 2
10 0550214 Outer Bearing - 3500# 2
11 0550215 Spindle Washer 2
12 0550216 Spindle Jam Nut – 1”-14 2
13 0550217 Tang Washer 2
14 0550218 Grease Cap – E/Z Lube - 3500# 2
15 0550219 Rubber Plug for EZ Lube Cap 2
16 14060033 Assy, Steering Linkage, AWD 1
17 12G-1010 Shoulder Bolt, 5/8” x 1 1/4” (1/2”-13) 2
18 0150305 5/8 Flat Washer 2
19 0150304 1/2 Flat Washer 2
20 0150206 1/2-13 Lock Nut 2
21 0300118A11 Hyd Mtr - 2500-4 Drv w/ 2 Mtrs, LH 1
22 0300118A1 Hyd Mtr - 2500-4 Drv w/ 2 Mtrs, RH 1
23 0300105W Hydraulic Cylinder 2 x 6 1
24 0300105O Prince Cyl. Pin - Long 2
25 Hitch Pin Clip (with 0300105O) 4
26 0150801 Hardened Spring Bushing – 1” 2
27 0150805 Hardened Spring Bushing – 5/8” 2
28 0150106G 1/2”-13 x 2 3/4” HHCS 8
29 Woodruff Key – 1/4” x 1” (with motor) 2
30 0150304 1/2 Flat Washer 8
31 Axle Nut – 1” Slotted Hex (with motor) 2
32 0150501 Cotter Pin – 3/16 x 2 2
33 Weld-on Seal Ring 2
To Next Page
