51
CYLINDER HEAD
SENSOR (HIGH STAGE
DISCHARGE TEMP)
(NOT SHOWN)
1/4" NPT HIGH
STAGE
PRESSURE TAP
TERMINAL BOX
IF PORT NOT
AVAILABLE TAP
TUBING HERE
IF AVAILABLE USE
PORT ON SERVICE
VALVE TO DESUPERHEAT
LIQUID INJECTION FITTING
PN 2TA1004
HIGH STAGE
INLET
NAMEPLATE
DISCHARGE
SERVICE
VALVE
HIGH SIDE
CYLINDER HEAD
OIL LEVEL
SIGHT GLASS
CRANKCASE HEATER
(ACCESSORY)
INSERTS INTO WELL
IN BOTTOM COVER
NOTE: Bolt sizes and thread pitch: Compressors are built using English unit
bolts. The bolts have no exact metric equivalents. Therefore, to prevent possible
cross-threading, loose bolts, or damage to threaded portions of the casing,
comparable metric measurements are not included.
Fig. 14B — 06CC Compressor (16 to 37 Cfm), 06D Body Motor
End Connection Points
