74 Specifications subject to change without notice. 38MGR-04SM
DISASSEMBLY INSTRUCTIONS SIZE 18 (CONT)
2) Remove the big handle
screws (4), and remove the
big handle.
3) Remove the terminal board
screws (2) and the right-rear
panel screws (7), then
remove the right rear panel.
Front panel screws
Big handle
screws
Terminal board
screws
Right-rear
panel screws
Right-rear
panel screws
