Carrier 38MGR Series - Page 88

88 Specifications subject to change without notice. 38MGR-04SM
DISASSEMBLY INSTRUCTIONS SIZE 24 (CONT)
7The
expansion
valve
How to remove the expansion
valve
1) Complete steps in the “Panel
Plate and ”Fan Assembly”
sections.
2) Remove the electrical parts.
See the “Electrical Parts”
section.
3) Remove the coils.
4) Detach the welded parts of
the expansion valves and
the pipes.
Expansion
Valves
