90 Specifications subject to change without notice. 38MGR-04SM
DISASSEMBLY INSTRUCTIONS SIZE 30 (CONT)
6) Remove the terminal board
screws (2), the water
collector screws, and the
right-rear panel screws (15),
and then remove the
right-rear panel.
5) Remove the front panel
screws (8) and remove the
front panel.
Front panel screws
Right front side
panel screws
Front panel screws
Front panel screws
Front panel screws
