38MGR-04SM Specifications subject to change without notice. 91

DISASSEMBLY INSTRUCTIONS SIZE 30 (CONT)

2 Fan

assembly

How to remove the fan

assembly

1) Remove the top cover, right

front side panel and the

front panel as described in

the “Panel Plate” section.

2) Remove the hex nut

securing the fan.

Right-rear panel screws

Terminal

board

screws
