Carrier 38VMA Series - Page 27

Table 11 - Cooling Compressor Control (38VMA144HDS)
Capacity
QCr
Frequency
Capacity
QCr
Frequency
Capacity
QCr
Frequency
38VMA144(1) 38VMA144(2) 38VMA144(1) 38VMA144(2) 38VMA144(1) 38VMA144(2)
1 20Hz 20 54Hz 38 + 36 39 74 + 72
2 20Hz 21 56Hz 39 + 38 40 76 + 74
3 20Hz 22 58Hz 42 + 40 41 78 + 76
4 20Hz 23 60Hz 44 + 42 42 80 + 78
5 20Hz 24 62Hz 46 + 44 43 82 + 80
6 20Hz 25 64Hz 48 + 46 44 84 + 82
7 20Hz 26 68Hz 52 + 46 45 86 + 84
8 22Hz 27 70Hz 52 + 48 46 86 + 84
9 24Hz 28 54 + 52 47 86 + 84
10 26Hz 29 56 + 54 48 86 + 84
11 28Hz 30 58 + 56 49 86 + 84
12 32Hz 31 60 + 58 50 86 + 84
13 36Hz 32 62 + 60 51 86 + 84
14 39Hz 33 63 + 61 52 86 + 84
15 42Hz 34 64 + 62 53 86 + 84
16 44Hz 35 66 + 64 54 86 + 84
17 46Hz 36 68 + 66 55 86 + 84
18 48Hz 37 70 + 68 56 86 + 84
19 52Hz 38 72 + 70
Table 12 - Heating Compressor Control (38VMA072, 096, 120HDS)
Capacity QHr
Frequency
Capacity QHr
Frequency
38VMA072 38VMA096 38VMA120 38VMA072 38VMA096 38VMA120
1 20Hz 20Hz 20Hz 21 62Hz 62Hz 62Hz
2 20Hz 20Hz 20Hz 22 64Hz 64Hz 64Hz
3 21Hz 21Hz 21Hz 23 68Hz 68Hz 68Hz
4 22Hz 22Hz 22Hz 24 70Hz 70Hz 70Hz
5 23Hz 23Hz 23Hz 25 72Hz 72Hz 72Hz
6 24Hz 24Hz 24Hz 26 74Hz 74Hz 74Hz
7 26Hz 26Hz 26Hz 27 76Hz 76Hz 76Hz
8 28Hz 28Hz 28Hz 28 78Hz 78Hz
9 32Hz 32Hz 32Hz 29 80Hz 80Hz
10 36Hz 36Hz 36Hz 30 82Hz 82Hz
11 39Hz 39Hz 39Hz 31 84Hz 84Hz
12 42Hz 42Hz 42Hz 32 86Hz 86Hz
13 44Hz 44Hz 44Hz 33 86Hz 86Hz
14 46Hz 46Hz 46Hz 34 88Hz
15 48Hz 48Hz 48Hz 35 88Hz
16 52Hz 52Hz 52Hz 36 90Hz
17 54Hz 54Hz 54Hz 37 90Hz
18 56Hz 56Hz 56Hz 38 92Hz
19 58Hz 58Hz 58Hz 39 92Hz
20 60Hz 60Hz 60Hz
27
