PERFORMANCE DATA (CONT.)
INSTANTANEOUS AND INTEGRATED HEATING RATINGS
40QNQ018 HIGH WALL WITH 38QRF018
Air Temperature
Entering Indoor
Unit ° F (° C)
Indoor
Airflow
(CFM)
L --- M --- H
Item
Air Temperature Entering Outdoor Coil ° F (° C)
17 ( ---8.3) 27 ( ---2.8) 37 (2.8) 47 (8.3) 57 (13.9)
Instant. Integrated Instant. Integrated Instant. Integrated Instant. Integrated Instant. Integrated
Rating Rating Rating Rating Rating Rating Rating Rating Rating Rating
55 (12.8)
460
Cap 10.77 9.82 13.37 11.87 15.53 14.13 17.20 17.20 20.58 20.58
kW 1.20 1.31 1.42 1.53 1.71
525
Cap 10.81 9.86 13.55 12.03 15.73 14.32 17.43 17.43 20.99 20.99
kW 1.19 1.26 1.35 1.45 1.62
645
Cap 10.92 9.95 13.79 12.25 15.97 14.54 17.80 17.80 21.53 21.53
kW 1.14 1.21 1.28 1.37 1.51
60 (15.6)
460
Cap 10.54 9.61 13.14 11.67 15.27 13.89 16.92 16.92 20.21 20.21
kW 1.25 1.37 1.46 1.60 1.72
525
Cap 10.64 9.70 13.32 11.83 15.50 14.11 17.17 17.17 20.63 20.63
kW 1.23 1.32 1.43 1.52 1.70
645
Cap 10.74 9.79 13.56 12.04 15.77 14.35 17.53 17.53 21.19 21.19
kW 1.20 1.26 1.34 1.44 1.58
65 (18.3)
460
Cap 10.31 9.40 12.92 11.47 15.02 13.67 16.64 16.64 19.87 19.87
kW 1.30 1.42 1.55 1.68 1.80
525
Cap 10.43 9.51 13.09 11.62 15.25 13.88 16.91 16.91 20.26 20.26
kW 1.28 1.38 1.49 1.60 1.76
645
Cap 10.63 9.69 13.33 11.84 15.54 14.14 17.26 17.26 20.81 20.81
kW 1.24 1.32 1.41 1.51 1.64
70 (21.1)
460
Cap 10.08 9.19 12.80 11.37 14.75 13.43 16.35 16.35 19.50 19.50
kW 1.36 1.46 1.60 1.76 1.93
525
Cap 10.18 9.28 12.85 11.42 14.99 13.64 16.64 16.64 19.90 19.90
kW 1.34 1.45 1.54 1.68 1.82
645
Cap 10.40 9.48 13.09 11.62 15.27 13.90 17.00 17.00 20.43 20.43
kW 1.29 1.38 1.47 1.56 1.72
75 (23.9)
460
Cap 9.79 8.66 12.57 11.17 14.47 8.66 16.05 16.05 19.07 19.07
kW 1.41 1.51 1.67 1.84 2.04
525
Cap 9.89 8.89 12.69 11.27 14.72 8.89 16.35 16.35 19.55 19.55
kW 1.39 1.49 1.61 1.75 1.89
645
Cap 10.12 9.23 12.86 11.43 15.02 13.67 16.73 16.73 20.06 20.06
kW 1.35 1.45 1.53 1.66 1.76
80 (26.7)
460
Cap 9.47 8.64 12.29 10.91 14.20 12.92 15.64 15.64 18.75 18.75
kW 1.47 1.57 1.73 1.98 2.09
525
Cap 9.58 8.74 12.47 11.07 14.44 13.14 16.05 16.05 19.19 19.19
kW 1.45 1.54 1.66 1.89 1.99
645
Cap 9.82 8.66 12.70 11.28 14.76 13.43 16.48 16.48 19.72 19.72
kW 1.41 1.49 1.62 1.76 1.85
Indicates Rating Condition (*Integrated Capacity) Indicates Integrated Rating
Cap --- Heating Capacity (100 Btuh), Includes indoor fan motor heat
kW --- Total Power Input, includes compressor motor power input, outdoor fan motor power input, and indoor fan motor power input
Note: Integrated Capacity is maximum (instantaneous ) capacity less the effect of frost on the outdoor coil and the heat to defrost it.
40QNC,QNQ/38HDF,QRF
