Carrier 40QNQ User Manual

21
PERFORMANCE DATA (CONT.)
INSTANTANEOUS AND INTEGRATED HEATING RATINGS
40QNQ024 HIGH WALL 38QRF024
Air Temperature
Entering Indoor
Unit ° F (° C)
Indoor
Airflow
(CFM)
L --- M --- H
Item
Air Temperature Entering Outdoor Coil ° F (° C)
17 ( ---8.3) 27 (--- 2.8) 37 (2.8) 47 (8.3) 57 (13.9)
Instant.
Rating
Integrated
Rating
Instant.
Rating
Integrated
Rating
Instant.
Rating
Integrated
Rating
Instant.
Rating
Integrated
Rating
Instant.
Rating
Integrated
Rating
55 (12.8)
460
Cap 13.68 12.48 16.49 14.64 19.01 17.30 22.17 22.17 25.24 25.24
kW 1.56 1.69 1.87 2.07 2.30
525
Cap 13.81 12.59 16.65 14.79 19.25 17.52 22.44 22.44 25.66 25.66
kW 1.53 1.64 1.79 1.96 2.21
645
Cap 14.01 12.77 16.85 14.97 19.53 17.78 22.86 22.86 26.24 26.24
kW 1.48 1.59 1.69 1.83 2.03
60 (15.6)
460
Cap 13.40 12.22 16.22 14.41 18.68 17.00 21.80 21.80 24.72 24.72
kW 1.63 1.76 1.97 2.19 2.37
525
Cap 13.56 12.36 16.33 14.51 18.99 17.28 22.17 22.17 25.28 25.28
kW 1.60 1.73 1.89 2.07 2.31
645
Cap 13.78 12.57 16.59 14.74 19.31 17.57 22.54 22.54 25.88 25.88
kW 1.54 1.66 1.77 1.93 2.13
65 (18.3)
460
Cap 13.08 11.93 15.98 14.19 18.45 16.79 21.49 21.49 24.27 24.27
kW 1.71 1.82 2.05 2.28 2.53
525
Cap 13.26 12.09 16.11 14.31 18.69 17.01 21.88 21.88 24.81 24.81
kW 1.67 1.79 1.98 2.19 2.36
645
Cap 13.52 12.33 16.32 14.50 19.04 17.32 22.29 22.29 25.51 25.51
kW 1.61 1.73 1.86 2.03 2.26
70 (21.1)
460
Cap 12.74 11.61 15.72 13.96 18.19 16.55 21.10 21.10 23.60 23.60
kW 1.78 1.88 2.13 2.37 2.74
525
Cap 12.93 11.79 15.86 14.09 18.37 16.72 21.55 21.55 24.31 24.31
kW 1.75 1.85 2.09 2.29 2.55
645
Cap 13.21 12.04 16.09 14.29 18.75 17.06 22.01 22.01 25.02 25.02
kW 1.68 1.79 1.96 2.15 2.35
75 (23.9)
460
Cap 12.37 8.66 15.42 13.70 17.91 8.66 20.76 20.76 23.64 23.64
kW 1.85 1.95 2.20 2.46 2.82
525
Cap 12.56 8.89 15.58 13.84 18.04 8.89 21.40 21.40 23.74 23.74
kW 1.82 1.91 2.17 2.35 2.71
645
Cap 12.86 11.72 15.84 14.07 18.42 16.76 21.71 21.71 24.63 24.63
kW 1.76 1.86 2.05 2.22 2.50
80 (26.7)
460
Cap 11.97 10.91 15.04 13.36 17.59 16.01 20.43 20.43 23.10 23.10
kW 1.93 2.03 2.26 2.58 2.69
525
Cap 12.16 11.09 15.28 13.57 17.75 16.16 21.00 21.00 23.41 23.41
kW 1.89 1.98 2.24 2.50 2.61
645
Cap 12.47 8.66 15.56 13.82 18.13 16.50 21.57 21.57 24.21 24.21
kW 1.84 1.92 2.15 2.35 2.50
Indicates Rating Condition (*Integrated Capacity) Indicates Integrated Rating
Cap --- Heating Capacity (100 Btuh), Includes indoor fan motor heat
kW --- Total Power Input, includes compressor motor power input, outdoor fan motor power input, and indoor fan motor power input
Note: Integrated Capacity is maximum (instantaneous ) capacity less the effect of frost on the outdoor coil and the heat to defrost it.
40QNC,QNQ/38HDF,QRF
