Carrier 42C Series Installation Instructions

8
Table 2 — Physical Data — 42D Series
UNIT SIZE 42D 06 08101214161820
NOMINAL AIRFLOW (cfm) 600 800 1000 1200 1400 1600 1800 2000
SHIPPING WEIGHT (lb)
a
42DA 64 79 90 108 119 124 141 151
42DC 94 107 150 169 174 178 195 220
42DE 150 160 170 195 205 215 230 235
42DF 157 167 177 202 215 225 240 255
42DD 135 145 155 180 190 200 215 230
COIL WATER WEIGHT
(Approx lb per row of coil)
1.3 1.6 1.9 2.3 2.7 3.0 3.4 3.7
COILS
FPI 10 fins/in.
Coil Face Area (sq ft) 1.6 2.1 2.5 3.0 3.5 4.1 4.6 5.0
MOTOR (qty) 1 1122222
BLOWER (qty) 1 1122222
FILTERS
b,c,d

Nominal Size (in.) (1 in. thick)
42DA
14 x 21
(356 x 533)
14x 26
(356 x 660)
14 x 30
(356 x 762)
14 x 35
(356 x 889)
14 x 40
(356 x 1016)
14 x 45
(356 x 1143)
14 x 50
(356 x 1270)
14 x 54
(356 x 1372)
42DC
14 x 21
(356 x 533
14 x 26
(356 x 660)
14 x 30
(356 x 762
14 x 35
(356 x 889)
14 x 40
(356 x 1016)
14 x 45
(356 x 1143)
14 x 50
(356 x 1270)
14 x 54
(356 x 1372)
42DE
14 x 14-3/4
(356 x 375)
14 x 19-3/4
(356 x 502)
14 x 23-3/4
(356 x 603
14 x 28-3/4
(356 x 730)
14 x 33-3/4
(356 x 857)
14 x 38-3/4
(356 x 984)
14 x 43-3/4
(356 x 1111)
14 x 47-3/4
(356 x 1213)
42DF
14 x 14
(356 x 356)
14 x 20
(356 x 508)
14 x 24
(356 x 610)
14 x 28
(356 x 711)
14 x 34
(356 x 864)
14 x 38
(356 x 965)
14 x 44
(356 x 1118)
14 x 48
(356 x 1219
42DD
e
(Front Return)
21 x 12-3/4
(533 x 324)
26 x 12-3/4
(660 x 324)
30 x 12-3/4
(762 x 324)
35 x 12-3/4
(889 x 324)
40 x 12-3/4
(1016 x 324)
45 x 12-3/4
(1143 x 324)
50 x 12-3/4
(1270 x 324)
54 x 12-3/4
(1372 x 324)
(Bottom Return)
20 x 12-3/4
(508 x 324)
25 x 12-3/4
(635 x 324)
29 x 12-3/4
(737 x 324)
34 x 12-3/4
(864 x 324)
39 x 12-3/4
(991 x 324)
44 x 12-3/4
(1118 x 324)
49 x 12-3/4
(1245 x 324)
53 x 12-3/4
(1346 x 324)
Qty 1
SUPPLY DUCT COLLAR 1 in.
PIPING CONNECTIONS
Coil Inlet/Outlet (in. OD)
1 and 2 Row 5/8 5/8 5/8 5/8 5/8 5/8 5/8 5/8
3 Row 5/8 5/8 7/8 7/8 7/8 7/8 7/8 7/8
4 Row 7/8 7/8 7/8 7/8 7/8 1-1/8 1-1/8 1-1/8
5 Row 7/8 7/8 7/8 7/8 1-1/8 1-1/8 1-1/8 1-1/8
6 Row 7/8 7/8 7/8 7/8 1-1/8 1-1/8 1-1/8 1-1/8
8 Row 1-1/8 1-1/8 1-1/8 1-1/8 1-5/8 1-5/8 1-5/8 1-5/8
Tell-Tale Drain 5/8 OD
NOTE(S):
a. Calculate Operating Weight of unit: Shipping Weight + Coil Water Weight x Number of Coil Rows
b. Filter sizes for the DA model are recommended filter sizes only. No filter is factory provided with this model.
c. Sizes shown are nominal ordering sizes.
d. Filter sizes for the DF model are for filter included with standard aluminum filter grille.
e. Use when bottom return and 6 in. legs are supplied.
