Table 3 — Physical Data — 42V Series
UNIT SIZE 42V 01 02 03 04 06 08 10 12
NOMINAL AIRFLOW (cfm) 150 200 300 400 600 800 1000 1200
SHIPPING WEIGHT (lb)
a
42VAD —4247577779108127
42VBD — 63 68 82 99 101 133 154
42VFD — 64 69 83 100 102 135 156
42VCA — 72 100 108 154 — — —
42VEA — 50 60 72 110 — — —
42VGA 40— 74—————
COILS
FPI (42VAD, VBD, VFD) 12 fins/in.
FPI (42VCA, VEA, VGA) 10 fins/in.
MOTOR (qty)
42VCD, VBD, VFD —1111122
42VCA, VEA —1 1 1 2 ———
42VGA 1— 2 —————
BLOWER (qty)
42VCD, VBD, VFD —1122244
42VCA, VEA —2 2 2 4 ———
42VGA 1— 2 —————
FILTERS
Nominal Size (in.) (1 in. thick)
42VCD, VBD, VFD —
7-3/4 x
21-3/4
7-3/4 x
21-3/4
7-3/4 x
31-3/4
7-3/4 x
41-3/4
7-3/4 x
43-3/4
7-3/4 x
57-3/4
7-3/4 x
65-3/4
42VCA, VEA — 7 x 21-3/4 7 x 26-3/4 7 x 34-3/4 7 x 48-3/4 — — —
42VGA 10 x 14-1/2 — 10 x 28 — — — — —
Qty 11111111
SUPPLY DUCT COLLAR 1 in.
PIPING CONNECTIONS 
(Sweat) (in.)
Coil Outlet and Inlet 5/8 OD
Drain Connection 3/4 MPT
NOTE(S):
a. Calculate operating weight of unit: shipping weight + coil water weight x number of coil rows.
