Carrier 48HC*04–14 User Manual

11
REMOTE VFD KEYPAD REFERENCE
Table 4 – S RT Unit VFD Parameters — 48HC** 08--12
VFD
Part
Number
ABB Part N umber Description
Motor
Part
Number
Voltage
(9905)
Nom
Amps
(9906)
Motor
Nom
Freq
(9907)
Nom RPM
(9908)
Nom
HP
(9909)
Const
Speed Sel
(1201)
Const
Speed 1
(1202)
Const
Speed 2
(1203)
Const
Speed 3
(1204)
Relay
Out 3
(1403)
Max
Amps
(2003)
Min
Freq
(2007)
Max
Freq
(2008)
Switch
Freq
(2606)
Start
Fcn
(2101)
Stop
Fcn
(2102)
Accel/
Decel
(2201)
Accel
(2202)
Decel
(2203)
HK30WA364 A C H 5 5 0 --- U 0 --- 01 2 A --- 2 1.7 HP 230V HD56FR233 230 5.8 60Hz 1725 1.7 DI 2,3 40Hz 60Hz 60Hz
16 FLT/
Alarm
6.7 0Hz 60Hz 4kHz Auto Ramp Not Sel 30 sec 30 sec
HK30WA356 A C H 5 5 0 --- U 0 --- 01 2 A --- 2 1.7 HP 460V HD56FR463 460 2.9 60Hz 1725 1.7 DI 2,3 40Hz 60Hz 60Hz
16 FLT/
Alarm
3.3 0Hz 60Hz 4kHz Auto Ramp Not Sel 30 sec 30 sec
HK30WA366 A C H 5 5 0 --- U 0 --- 01 7 A --- 2 1.7 HP 575V HD56FR579 575 3.1 60Hz 1725 1.7 DI 2,3 40Hz 60Hz 60Hz
16 FLT/
Alarm
3.6 0Hz 60Hz 4kHz Auto Ramp Not Sel 30 sec 30 sec
HK30WA352 A C H 5 5 0 --- U 0 --- 02 4 A --- 2 2.4 HP 230V HD56FE653 230 7.9 60Hz 1725 2.4 DI 2,3 40Hz 60Hz 60Hz
16 FLT/
Alarm
9.1 0Hz 60Hz 4kHz Auto Ramp Not Sel 30 sec 30 sec
HK30WA356 A C H 5 5 0 --- U 0 --- 06 A 9 --- 4 2.4 HP 460V HD56FE653 460 4 60Hz 1725 2.4 DI 2,3 40Hz 60Hz 60Hz
16 FLT/
Alarm
4.6 0Hz 60Hz 4kHz Auto Ramp Not Sel 30 sec 30 sec
HK30WA360 A C H 5 5 0 --- U 0 --- 06 A 9 --- 4 2.4 HP 575V HD56FE577 575 3.4 60Hz 1725 2.4 DI 2,3 40Hz 60Hz 60Hz
16 FLT/
Alarm
3.9 0Hz 60Hz 4kHz Auto Ramp Not Sel 30 sec 30 sec
HK30WA352 A C H 5 5 0 --- U 0 --- 06 A 9 --- 4 2.9 HP 230V HD58FE654 230 9.2 60Hz 1725 2.9 DI 2,3 40Hz 60Hz 60Hz
16 FLT/
Alarm
10.6 0Hz 60Hz 4kHz Auto Ramp Not Sel 30 sec 30 sec
HK30WA356 A C H 5 5 0 --- U 0 --- 08 A 8 --- 4 2.9 HP 460V HD58FE654 460 4.6 60Hz 1725 2.9 DI 2,3 40Hz 60Hz 60Hz
16 FLT/
Alarm
5.3 0Hz 60Hz 4kHz Auto Ramp Not Sel 30 sec 30 sec
HK30WA353 A C H 5 5 0 --- U 0 --- 01 2 A --- 4 3.7 HP 230V HD60FE656 230 11.2 60Hz 1725 3.7 DI 2,3 40Hz 60Hz 60Hz
16 FLT/
Alarm
12.9 0Hz 60Hz 4kHz Auto Ramp Not Sel 30 sec 30 sec
HK30WA357 A C H 5 5 0 --- U 0 --- 03 A 9 --- 6 3.7 HP 460V HD60FE656 460 5.6 60Hz 1725 3.7 DI 2,3 40Hz 60Hz 60Hz
16 FLT/
Alarm
6.4 0Hz 60Hz 4kHz Auto Ramp Not Sel 30 sec 30 sec
HK30WA361 A C H 5 5 0 --- U 0 --- 06 A 1 --- 6 3.7 HP 575V HD58FE577 575 4.2 60Hz 1725 3.7 DI 2,3 40Hz 60Hz 60Hz
16 FLT/
Alarm
4.8 0Hz 60Hz 4kHz Auto Ramp Not Sel 30 sec 30 sec
HK30WA354 A C H 5 5 0 --- U 0 --- 09 A 0 --- 6 5.3 HP 230V HD60FK658 230 13 60Hz 1740 5.3 DI 2,3 40Hz 60Hz 60Hz
16 FLT/
Alarm
150 0Hz 60Hz 4kHz Auto Ramp Not Sel 30 sec 30 sec
HK30WA358 A C H 5 5 0 --- U 0 --- 07 A 5 --- 2 5.3 HP 460V HD60FK658 460 6.4 60Hz 1740 5.3 DI 2,3 40Hz 60Hz 60Hz
16 FLT/
Alarm
7.4 0Hz 60Hz 4kHz Auto Ramp Not Sel 30 sec 30 sec
HK30WA362 A C H 5 5 0 --- U 0 --- 02 A 7 --- 6 5.3 HP 575V HD60FE576 575 5.4 60Hz 1725 5.3 DI 2,3 40Hz 60Hz 60Hz
16 FLT/
Alarm
6.2 0Hz 60Hz 4kHz Auto Ramp Not Sel 30 sec 30 sec
