5.4 - Electrical data notes for the hydraulic module
The pumps that are factory-installed in these units have motors with e󰀩ciency class IE3 for > 0.75 kW motors. The additional electrical
data required
(1)
is as follows:
Motors for unit high-pressure pumps (option 116R, 116S, 116V, 116W)
No.
(2)
Description
(3)
040R 045R 050R 055R 060R 070R 080R 090R 100R 120R 140R 160R
1 Nominal e󰀩ciency at full load and nominal voltage % 84,8 84,8 84,8 84,8 84,8 84,8 84,8 84,8 84,8 85,9 85,9 85,9
1 Rated e󰀩ciency at 75% of full load and nominal voltage % 82,2 82,2 82,2 82,2 82,2 82,2 82,2 82,2 82,2 84 84 84
1 Rated e󰀩ciency at 50% of full load and nominal voltage % 79 79 79 79 79 79 79 79 79 82,1 82,1 82,1
2 E󰀩ciency level - IE3
3 Year of manufacture -
This information varies depending on the manufacturer and model at
the time of incorporation. Please refer to the motor name plates,
4
Manufacturer's name and trademark, commercial
registration number and head o󰀩ce of manufacturer
- Same as above
5 Product model number - Same as above
6 Number of motor poles - 2
7-1
Nominal shaft power output at full load and nominal voltage
(400 V)
kW 1,7 1,7 1,7 1,7 1,7 1,7 1,7 1,7 1,7 2,2 2,2 2,2
7-2 Maximum input power (400 V)
(4)
kW 2,40 2,40 2,40 2,40 2,40 2,40 2,40 2,40 2,40 2,90 2,90 2,90
8 Rated input frequency Hz 50
9-1 Nominal voltage V 3 x 400
9-2 Maximum current drawn (400 V)
(5)
A 4,2 4,2 4,2 4,2 4,2 4,2 4,2 4,2 4,2 5,0 5,0 5,0
10 Nominal speed
rps
- rpm
2870 2870 2870 2870 2870 2870 2870 2870 2870 2855 2855 2855
11 Product disassembly, recycling or disposal at end of life -
Disassembly using standard tools. Disposal and recycling using an
appropriate company
12 Operating conditions for which the motor is specically designed
I - Altitudes above sea level m < 1000
(6)
II - Ambient air temperature °C < 40
III - Maximum operating temperature °C
Please refer to the operating conditions given in this manual or in the
specic conditions given in the selection programs.
IV - Potentially explosive atmospheres - Non ATEX environment
(1) Required by regulation No. 640/2009 concerning the application of directive 2009/125/EC on the eco-design requirements for electric motors.
(2) Item number imposed by regulation No. 640/2009, annex I2b.
(3) Description given by regulation No. 640/2009, annex I2b.
(4) To obtain the maximum input power for a unit with hydraulic module, add the "maximum operating input power" for the unit (see Electrical data table) to the pump power.
(5) To obtain the maximum unit operating current draw for a unit with hydraulic module add the "maximum unit operating current draw" (see Electrical data table) to the
pump current draw.
(6) Above 1000 m, a degradation of 3% for each 500 m should be taken into consideration.
