Carrier Connect - To connect a remote input (sensor or contacts)

Wiring
the Carrier® Connect™ Wi
-Fi Thermostat
Carrier Connect™
Wi-Fi Thermostat Carrier Proprietary and Confidential CARRIER CORPORATION ©2017
Installation Guide 9 All rights reserved
9 Turn on the 24 Vac power. The thermostat displays the HOME screen. See HOME (page 27) for details.
10 Configure your system as described in this document.
To connect a remote input (sensor or contacts)
NOTE Use the specified type of wire and cable for maximum signal integrity.
Power
N/A
Description
Stranded, twisted pair
Conductor
If < 100 ft (30.5 meters) 22 AWG, unshielded
If > 100 ft (30.5 meters) 22 AWG, shielded
Maximum length
500 feet (152 meters)
Insulation
Plenum rated
