On-Screen indicators
1
2
4
5
6
7
8
9
10 11 12 13 14
15
16
17
18
19
20
21
22
23
24
25262728
Domestic Water warning
icon (disinfection failed)
Domestic water mode
Domestic water tank
electric heater (booster
heater)
Gas boiler "Away" set point selected Solar
System mode o "Sleep" set point selected Electric Heater 1 and 2
Room air temperature Service/Installer Mode
Heat pump request / Silent
mode
Zone icon Relative humidity
Domestic hot water valve
activated
Cool Mode Heat Mode Zone number
Time Display Area Keypad lock
Outdoor temperature Schedule Activated
Day of the week Disinfection cycle
Alarm Home Antifreeze
"Home" set point selected Celsius
English
