Carrier VECTOR 1800 MT - Figure 2-7. Control Module

9
2-13
62-11039
PC
CARD SLOT
F4
(7.5A)
NOT
USED
RUN RELAY (K2)
F3 (7.5A)
SPEED RELAY (K1)
F2 (10A)
F1 (7.5A)
DC CURRENT
SENSOR
6MP (DISPLAY/KEYPAD
CIRCUIT)
5MP
FET LEDs
SeeTable2-4
4MP
1MP (WHITE)
TEMP & PRESSURE
INPUTS
2MP (BLACK)
STEPPER MOTORS,
(EVXV, CSMV)
3MP (GREY)
FET OUT-
PUTS
PC CARD FAULT LED
(RED)
PC CARD STATUS
LED (GREEN)
MICRO STATUS LED
(GREEN)
QC1 (SYSTEM POWER
12+VDC FROM BATTERY)
QC2 (MICRO GROUND)
RELAY POWER
QC8 (12+ VDC
LED29
LED28
LED30 (GPR)
LED31 (SSR)
QC5 (NOT
USED)
QC4 (+12V OUTPUT
TO RR)
QC3 (+12V OUTPUT
TO SR)
LED27
QC9
Figure 2-7. Control Module
