Carrier VECTOR 1800 MT - Table 2-4. Field Effect Transistors

2-14
62-11039
Table 2-4. FIELD EFFECT TRANSISTORS (T ransistors not listed are spares)
STANDARD
FET DESIGNATION
FET1 Condenser fan motor
FET2 Compressor contactor
FET3 Generator contactor
FET10 Heat contactor 1
FET18 Buzzer
FET19 Standby contactor
FET20 Evaporator motor
FET21 Heat contactor 2
FET22 Rear unloader
FET23 Front unloader
LIGHT BAR OPTIONS
FET DESIGNATION
FET7 Start--Stop/Continuous
FET8 Heat Light
FET14 Fault Light
FET15 Out--Of--Range Light
FET16 Defrost Light
FET17 Cool Light
