To change multiple configuration parameters:
To make another modification to configuration, depress the
"
SET TIME/TEMP" button. This will toggle between selecting the
Configuration Option and the Configuration Value.
To change the selection, press the "up" and "down" arrows
until the desired configuration selection is displayed.
1- FAHRENHEIT OR CELSIUS
Select between Fahrenheit (F) or Celsius (C) operation.
Factory default is Celsius.
To select while in configuration mode:
• The Configuration Option ("1-") and the current selection
should be displayed.
• Depress the "
SET TIME/TEMP" button to alter the current
selection (current selection will now blink).
• Use either the "up" or "down" button to change between "F" or "C".
• To end configuration, either depress the "
END PROGRAM" button
or do not press any buttons for 20 seconds.
2- ROOM THERMISTOR OVERRIDE
Select whether the units in zone 1 will use room temperature
sensor in the Zone Manager "
ON"or whether they will use the air
sensor at the units "
OF". Factory default is OFF.
If the chosen option is "
ON" the room air temperature will be
displayed.
CAUTION:
If the room air sensor on the Zone Manager is selected,
installation of the Zone Manager is critical.
To select while in configuration mode:
• Press the "up" or "down" button until "2-" is displayed.
• Depress the "
SET TIME/TEMP" button to alter the current
selection (current selection will now blink).
up
down
up
down
Configuration
